With its headquarters located in Delhi, India, Daksh Sheets and Plates is a well-known producer and supplier of high-performance alloy C263 foil that is designed to withstand harsh mechanical and thermal conditions. Serving vital industries like gas turbines, industrial heat treatment systems, and aerospace, Daksh has a solid reputation for accuracy, dependability, and quality. Their Alloy C263 foil is renowned for its exceptional weldability, oxidation resistance, and high-temperature strength. Daksh guarantees reliable performance and on-time delivery with the help of sophisticated manufacturing and strict quality control. They are a reliable partner for specialized alloy solutions in a variety of international industries because of their commitment to engineering excellence and client satisfaction.
About 50% nickel, 20% cobalt, 20% chromium, 6% molybdenum, 2% titanium, and 0.5% aluminum make up Alloy C263, a nickel-based superalloy. Excellent oxidation resistance, thermal stability, and formability are provided by this combination. C263 foil offers exceptional elongation properties, a yield strength of ~550 MPa, a tensile strength of ~885 MPa, and the capacity to retain mechanical integrity up to 980°C. Additionally, it can be precipitation-hardened, which improves its resistance to fatigue and creep. It is the perfect material for components subjected to structural loading and thermal cycling because of its ease of fabrication and weldability.
| Standard Specification : | AMS 5872 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | Ni | Co | Cr | Mo | Ti | Fe | Mn | Al | Si | Cu | C | B | S |
| Alloy C263 | 49 | 19-21 | 19-21 | 5.60-6.10 | 1.90-2.40 | 0.70 | 0.60 | 0.60 | 0.40 | 0.20 | 0.040 – 0.080 | 0.0050 | 0.0070 |
| Material | Temp °C | Yield Strength (Mpa) | Tensile Strength (Mpa) | Elongation % | Hardness HRC |
|---|---|---|---|---|---|
| Alloy C263 Solution Treated (AMS 5872 / BS HR206) | RT | – | – | – | 22.5 max |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | RT | 580 (typical) | 973 (typical) | 39 – | |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | 780 | 403 (min) | 541 (min) | 9 | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Properties | Metric | Imperial |
|---|---|---|
| Density | 8.359 g/cm3 | 0.302 lb/in3 |
| Melting point | 1300-1335°C | 2372-2471°F |
Alloy C263 foil provides excellent advantages for high temperature applications. It provides outstanding resistance to oxidation and creep, making it ideal for aerospace and industrial applications. The high weldability and formability of the alloy ensures easy fabrication in complex shapes. Its excellent thermal stability and resistance to cracking under thermal cycling enhances reliability in extreme conditions. Additionally, alloy C263 exhibits corrosion and oxidation resistance up to 980°C (1800°F), providing long durability. Its combination of strength, ductility and thermal performance makes it desirable in gas turbines and heat treatment equipment.
In applications requiring oxidation resistance, thermal fatigue strength, and high-temperature durability, such as power generation, aerospace, and industrial heat-treatment systems, alloy C263 foil is extensively utilized. It is perfect for hot-section parts of gas turbines, combustion chambers, afterburners, and jet engine components. It is also used in furnace liners, springs, seals, and heat-treating fixtures. Reliability in demanding applications that demand dimensional stability and longevity under mechanical and thermal stress is attributed to its formability, strength retention, and resistance to corrosion. For precision parts in high-performance settings, C263 foil is the recommended option.
