Daksh Sheets and Plates, a well-respected manufacturer and supplier based in Delhi, India, specializes in high-strength Aluminium 2024 T3511 Plates and Sheets. These products are specifically crafted for aerospace and structural applications that require top-notch mechanical performance. Aluminium 2024 is a heat-treatable alloy known for its impressive fatigue resistance, high strength-to-weight ratio, and good machinability. The T3511 temper signifies that the material has undergone controlled stretching and stress-relieving after heat treatment, making it perfect for precision engineering. Daksh provides 2024 T3511 sheets and plates in various sizes, all designed to meet international quality standards. These materials find extensive use in aerospace, defense, transportation, and structural components where strength and reliability are crucial.
Aluminium 2024 is mainly an aluminum-copper alloy, containing about 3.8–4.9% copper, 1.2–1.8% magnesium, 0.3–0.9% manganese, with the rest being aluminum. The T3511 temper indicates that the material has been solution heat-treated, stress-relieved through stretching, and naturally aged. It boasts impressive tensile strength (around 470–500 MPa), yield strength (325–345 MPa), and good fatigue resistance. However, its corrosion resistance is not as high as that of other aluminum alloys, which is why it’s often clad or coated. Its exceptional strength and machinability make it ideal for high-load, fatigue-sensitive applications, particularly in structural aerospace components.
| Standards | ASTM B209 / ASME SB209 |
| Temper | O,H12,H14,H16,H18,H19,H22,H24 |
| Thickness | 0.2-50 |
| Width | 100-2600 |
| Length | 500-10000 |
| Surface | Bright, polished, hair line, brush, sand blast, embossed, etching, etc. |
| Finish | Mill, Customer specific finish |
| Aluminum Sheet/ Plate Coating | PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating |
| Type | Hot-Rolled (HR) / Cold-Rolled (CR) Sheet |
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other |
| min. | Bal | 3.80 | 0.30 | 1.20 | ||||||
| max. | Bal | 0.50 | 0.50 | 4.90 | 0.90 | 1.80 | 0.10 | 0.25 | 0.15 | 0.05 |
| Temper | Tensile Strength | Yield Strength | Elongation |
| KSI | KSI | % | |
| (annealed) | 32 | 14 | 12 |
| T3 | 63 | 42 | 15 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Aluminium 2024 T3511 Sheets and Plates offer outstanding advantages, including exceptional strength and fatigue resistance, making them ideal for high-performance aerospace, military, and engineering applications. The T3511 temper enhances the material’s structural integrity, ensuring reliability in demanding environments. These sheets and plates feature an excellent strength-to-weight ratio, critical for weight-sensitive industries like aviation. Their superior machinability allows for precise fabrication and complex designs. While the alloy has moderate corrosion resistance, it can be treated for enhanced durability, ensuring long-lasting performance. Aluminium 2024 T3511 is a top choice for high-stress applications.
Yes, we offer custom sizes for Aluminium 2024 T3511 Plates and Sheets to meet specific project needs. Our team at Daksh Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@dakshsheetsandplates.co.in
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlCu4Mg1 | AU4G1 | 3.1355 | A92024 | AlCu4Mg1 | 2024 | AlCuMg2 |
| Sizes (mm) | Theoretical Mass KG/Plate |
|---|---|
| 2000 X 1000 X 0.5 | 2500 X 1250 X 0.5 |
| 2000 X 1000 X 0.7 | 2500 X 1250 X 0.7 |
| 2000 X 1000 X 0.9 | 2500 X 1250 X 0.9 |
| 2000 X 1000 X 1.2 | 2500 X 1250 X 1.2 |
| 3000 X 1500 X 1.2 | 2000 X 1000 X 1.6 |
| 2500 X 1250 X 1.6 | 3000 X 1500 X 1.6 |
| 2000 X 1000 X 2.0 | 2500 X 1250 X 2.0 |
| 3000 X 1500 X 2.0 | 2500 X 1250 X 2.5 |
| 2.79 | 4.36 |
| 3.91 | 6.10 |
| 5.02 | 7.85 |
| 6.74 | 10.46 |
| 15.01 | 8.93 |
| 13.95 | 20.09 |
| 11.16 | 17.44 |
| 25.11 | 21.80 |
Aluminium 2024 T3511 Plates and Sheets are extensively utilized in the aerospace and defense industries, thanks to their remarkable strength and fatigue resistance. Common applications include aircraft fuselage structures, wing skins, bulkheads, and other vital airframe components. They are also employed in transportation, marine, military, and high-performance motorsport sectors where lightweight yet strong materials are essential.
