In Delhi, India, Daksh Sheets and Plates is a reputable producer and supplier of high-quality aluminium 3003 plates and sheets. Our speciality is providing premium aluminium solutions that are formable, corrosion-resistant, and long-lasting. Because of its exceptional workability and resistance to atmospheric corrosion, aluminium 3003 is a commonly used alloy in both the commercial and industrial sectors. At Daksh, we guarantee accurate fabrication, prompt delivery, and tailored measurements to satisfy the demands of each client. We provide reliable product quality and support to a wide range of industries in India and export markets, supported by a robust infrastructure and a knowledgeable workforce.
A non-heat-treatable alloy, aluminium 3003 is primarily made of aluminium with 1.0–1.5% manganese, which increases the alloy’s strength compared to pure aluminium. Small amounts of iron and copper may also be present. With a yield strength of roughly 115 MPa and a tensile strength between 130 and 200 MPa, this alloy provides moderate strength. It has good formability, weldability, and corrosion resistance. Aluminium 3003 is perfect for applications needing both durability and ease of fabrication because it can be cold-worked to improve mechanical performance even though it cannot be heat-treated for increased strength.
| Standards | ASTM B209 / ASME SB209 |
| Temper | O,H12,H14,H16,H18,H19,H22,H24 |
| Thickness | 0.2-50 |
| Width | 100-2600 |
| Length | 500-10000 |
| Surface | Bright, polished, hair line, brush, sand blast, embossed, etching, etc. |
| Finish | Mill, Customer specific finish |
| Aluminum Sheet/ Plate Coating | PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating |
| Type | Hot-Rolled (HR) / Cold-Rolled (CR) Sheet |
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other |
| min. | Bal | 3.80 | 0.30 | 1.20 | ||||||
| max. | Bal | 0.50 | 0.50 | 4.90 | 0.90 | 1.80 | 0.10 | 0.25 | 0.15 | 0.05 |
| Temper | Tensile Strength | Yield Strength | Elongation |
| KSI | KSI | % | |
| (annealed) | 32 | 14 | 12 |
| T3 | 63 | 42 | 15 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Yes, we offer custom sizes for Aluminium 3003 Plates and Sheets to meet specific project needs. Our team at Daksh Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@dakshsheetsandplates.co.in
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlCu4Mg1 | AU4G1 | 3.0517 | A93003 | AlCu4Mg | 3003 | AlCuMg2 |
| Properties | Metric | Imperial |
| Tensile strength | 130 MPa | 18855 psi |
| Yield strength | 125 MPa | 18130 psi |
| Shear strength | 83 MPa | 12039 psi |
| Fatigue strength | 55 MPa | 7977 psi |
| Elastic modulus | 70-80 GPa | 10153-11603 ksi |
| Poisson’s ratio | 0.33 | 0.33 |
| Elongation | 10% | 10% |
| Hardness | 35 | 35 |
Industries that require excellent formability, moderate strength, and corrosion resistance frequently use aluminium 3003 plates and sheets. Typical uses include fuel tanks, storage tanks, kitchen appliances, wall cladding, and roofing sheets. It is utilised in the transportation industry for siding and roofing on trucks and trailers. Because of its smooth surface and ease of fabrication, it is also used in insulation panels, signage, and ductwork. The alloy provides a flexible solution for both industrial and architectural applications because of its resistance to moisture and chemicals, which makes it appropriate for HVAC parts and food processing machinery.
