Reputable aluminium 5005 coil manufacturer and supplier Daksh Sheets and Plates, with headquarters in Delhi, India, provides premium aluminium solutions for a variety of commercial and industrial uses. Daksh is renowned for its reliability, accuracy, and customer-focused service. They provide superior strength, corrosion resistance, and finish for their Aluminium 5005 Coils. To accommodate uses in electrical systems, architectural finishes, transportation, and construction, these coils come in a range of tempers and sizes. Daksh has made a name for itself as a leading supplier of aluminium coils in India and abroad thanks to its unwavering dedication to quality, prompt delivery, and technical assistance.
About 97.5% of aluminium, 0.8% magnesium, and trace amounts of iron, silicon, copper, and other elements make up aluminium 5005 coils. Although this alloy cannot be heated, cold working can strengthen it. It provides exceptional resistance to corrosion, especially in atmospheric and marine environments. With a yield strength of about 110 MPa and elongation of up to 15–20%, the typical tensile strength is between 145 and 190 MPa. Aluminium 5005 is appropriate for both structural and decorative applications due to its exceptional surface finish, moderate-to-high strength, and good weldability.
Standards : ASTM B209 / ASME SB209
Temper : O,H14,H16,H18,H19,H22,H24
Thickness : 0.1-4
Width : coil
Length : 100-1600
Surface : Bright, polished, hair line, brush, sand blast, embossed, etching, etc.
Finish :Mill, Customer specific finish
Aluminum Coil Coating : PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Coil
| Weight% | Al | Si | Fe | Cu | Mn | Cr | Mg | Zn | Others Each | Others Total |
| 5005 | Bal | 0.30 max | 0.70 max | 0.20 max | 0.20 max | 0.10 max | 0.50 / 1.10 | 0.25 max | 0.05 max | 0.15 max |
| Material | Temper | Tensile Strength (N/mm²) | Yield Strength (N/mm²) | Elongation on 50mm (%) | |||
| 0.5 mm | 0.8 mm | 1.3 mm | 2.6mm | ||||
| 5005 | 0 | 95-145 | – | 18 | 20 | 21 | 22 |
| 5005 | H12 | 125-170 | 80 | 4 | 5 | 6 | 8 |
| 5005 | H14 | 145-185 | 100 | 3 | 3 | 5 | 6 |
| 5005 | H18 | 185 min | 165 | 1 | 2 | 3 | 3 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Yes, we offer custom sizes for Aluminium 5005 Coils to meet specific project needs. Our team at Daksh Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@dakshsheetsandplates.co.in
In many industries where strength, resistance to corrosion, and visual appeal are essential, aluminium 5005 coils are used extensively. They are perfect for roofing, cladding, curtain walls, and ornamental facades in the architectural and construction industries. The alloy is a popular option for coloured or bright-finished architectural panels because of its exceptional anodising response. Because of its conductivity, it is utilised in electrical applications for wiring, bus bars, and enclosures. Additionally, aluminium 5005 is utilised in signage for long-lasting display boards, in transportation for body panels and trim, and in food processing equipment where corrosion resistance and hygienic conditions are critical.
