Copper (0.25–0.40%), chromium (0.40–0.70%), and nickel (0.25–0.50%) alloying elements improve the atmospheric corrosion resistance of ASTM A709 Grade 50W, a high-strength, low-alloy structural steel. It is perfect for heavy structural use because it has a minimum yield strength of 345 MPa and a tensile strength of 485–620 MPa. In many applications, paint is not necessary because the steel develops a stable, protective rust layer when exposed to the elements. A709-50W is renowned for its exceptional toughness, fatigue resistance, and weldability, particularly in load-bearing and bridge applications subjected to severe weather conditions.
| Thickness | Width | Length |
|---|---|---|
| 6 to 100 mm | 900 to 4800 mm | 3000 to 12000 mm |
| Standard | Services | Grades |
| ASTM A709 | welding, forming, thermal cutting | 50W, 50WT, 50WF |
| TYPE | THICKNESS (in) | MN (wt %) | C (MAX wt %) | S (MAX wt %) | NI (MAX wt %) | P (MAX wt %) | V (wt %) | SI (wt %) | CR (wt %) | CU (wt %) |
|---|---|---|---|---|---|---|---|---|---|---|
| B | 2.00 – 3.00 | 0.75 – 1.35 | 0.20 | 0.030 | 0.50 | 0.030 | 0.01 – 0.10 | 0.15 – 0.50 | 0.40 – 0.70 | 0.20 – 0.40 |
| A | 0.1875 – 2.00 | 0.80 – 1.25 | 0.19 | 0.030 | 0.40 | 0.030 | 0.02 – 0.10 | 0.30 – 0.65 | 0.40 – 0.65 | 0.25 – 0.40 |
| GRADE | THICKNESS (in) | ELONGATION IN 8″ 2) (MIN %) | TENSILE STRENGTH (MIN ksi) | YIELD STRENGTH 1) (MIN ksi) | ELONGATION IN 2″ 2) (MIN %) |
|---|---|---|---|---|---|
| 50WT | 0.1875 – 3.00 | 18 | 70 | 50 | 21 |
| 50W | 0.1875 – 3.00 | 18 | 70 | 50 | 21 |
| 50WF | 0.1875 – 2.50 | 18 | 70 | 50 | 21 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Daksh Sheets and Plates based in Hyderabad , India, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Yes, we offer custom sizes for ASTM A709-50W Corten Steel Sheet and Plate to meet specific project needs. Our team at Daksh Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@dakshsheetsandplates.co.in
Because of their great strength and resistance to corrosion, ASTM A709-50W Corten Steel Sheets and Plates are frequently used in the construction of bridges, highway overpasses, structural supports, railroad components, and load-bearing frameworks. It is an affordable infrastructure solution because of its weathering qualities, which enable structures to endure years of outdoor exposure without deteriorating. A709-50W is utilised in transmission towers, industrial buildings, and architectural structures where durability and beauty are crucial, in addition to transportation projects. It is a great option for crucial structural applications because of its capacity to lower maintenance costs and deliver enduring performance in harsh environmental conditions.
