The Hyderabad, India-based Daksh Sheets and Plates is a well-known producer and supplier of high-end metal goods with a focus on precisely engineered sheets, plates, and structural elements for a range of industrial uses. The Copper Nickel 70/30 Channel is one of our products; it is renowned for its remarkable mechanical strength, resistance to corrosion, and long-term dependability in challenging and maritime conditions. Developed to satisfy the demanding requirements of the water treatment, chemical, power, and marine industries, our CuNi 70/30 products combine cost-effective solutions with engineering excellence, supported by competitive pricing and timely service.
| Specifications | : | ASTM B151 / ASME SB151 |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Cu-Ni 70/30 Angle | : | 5mm to 9mm |
| Cu-Ni 70/30 Channel | : | 40mm*20mm~300mm*300mm |
| Cu-Ni 70/30 Beam | : | 3″ thru 12.31″ |
| Cu-Ni 70/30 Chain | : | 1/8 inch – 1/2 inch Diameter |
| Thickness | : | 3.0mm – 120mm |
| Length | : | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | : | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
| Cu-Ni 70/30 | 65 min | 1.0 max | 0.05 max | 29-33 max | 0.4-1.0 max | 1 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 0.323 lb/in3 at 68 F | 2260 F | 50000 psi | 20000 psi | 30 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Cupro Nickel 70/30 | 2.0882 | C71500 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Copper Nickel 70/30 Channel offer several advantages. They are insoluble, especially in ambient seawater, making them ideal for marine applications. The alloy also provides excellent resistance to biofouling, providing durability under extreme conditions. Its strength and compression durability make it suitable for high-pressure environments. In addition, CuNi 70/30 has excellent thermal conductivity and is easy to weld, providing versatility in manufacturing. Its low maintenance requirements and high resistance to scaling and pitting further enhance its industrial appeal.
Because of their exceptional resistance to corrosive and saline environments, copper nickel 70/30 channels are widely used in the energy, industrial, and marine sectors. Heat exchangers, desalination plants, shipboard piping systems, and seawater cooling systems are typical uses. These channels are also perfect for use in water treatment systems, pharmaceutical plants, power plants, and offshore oil platforms. They are a material of choice for marine condenser and evaporator systems due to their resistance to biofouling. Even in harsh environmental circumstances, CuNi 70/30 channels guarantee long service life, minimal maintenance, and operational dependability.
