Based in Hyderabad, India, Daksh Sheets and Plates is a top producer and supplier of premium metal goods designed to satisfy industrial demands. Industries throughout India and beyond rely on us for our robust and precisely engineered sheets, plates, and foils. The Copper Nickel 70/30 Foil is one of our best products; it is well known for its remarkable mechanical strength, corrosion resistance, and thermal stability. This alloy offers long-lasting performance even in the most demanding conditions, making it perfect for industrial and marine applications. Daksh Sheets and Plates is dedicated to providing high-performance, customized solutions that satisfy exacting quality requirements.
| Specifications | ASTM B122 |
| Dimensional specification | JIS, AISI, ASTM, GB, DIN, EN, etc |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Thickness | 4mm-100mm |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface Finish | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated) etc. |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Surface Finish | No.1, No.4, No.8 Mirror Finish, 2B |
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
| Cu-Ni 70/30 | 65 min | 1.0 max | 0.05 max | 29-33 max | 0.4-1.0 max | 1 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 0.323 lb/in3 at 68 F | 2260 F | 50000 psi | 20000 psi | 30 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Cupro Nickel 70/30 | 2.0882 | C71500 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Copper nickel 70/30 foil provides excellent corrosion resistance, especially in seawater and marine environments, making it ideal for shipbuilding, desalination and offshore applications Its high strength and delivery the durability ensures longevity even in harsh conditions. The excellent thermoelectric conductivity of the alloy makes it suitable for heat exchangers and electrical components. In addition, it resists biofouling, reduces maintenance costs, and improves productivity. The 70/30 configuration provides a balance of flexibility and rigidity, allowing for ease of manufacture while maintaining its design integrity in demanding applications.
70/30 copper nickel Because of their great resistance to corrosion and saltwater, foils are used extensively in the industrial and marine sectors. They are frequently used in desalination plants, condensers, and heat exchangers. These foils are utilized in shipbuilding for hull linings, seawater piping, and anti-fouling coatings to guarantee durability and stop biofouling. They are appropriate for cryogenic equipment, power generation systems, and electronic components due to their exceptional electrical conductivity. They are also used in chemical processing facilities, offshore oil and gas platforms, and other settings where corrosion resistance, conductivity, and durability are essential.
