Daksh Sheets and Plates stands out as a leading manufacturer and supplier of top-notch metal products, including Copper Sheets and Plates, right in the heart of Delhi, India. We pride ourselves on our commitment to quality and precision, serving various industries such as electrical, construction, and manufacturing. Our Copper Sheets and Plates are celebrated for their outstanding conductivity, durability, and resistance to corrosion. With cutting-edge manufacturing techniques and rigorous quality control, we guarantee that our products meet the highest standards, delivering dependable solutions for a wide array of industrial applications across India.
Our Copper Sheets and Plates are crafted from pure copper, typically boasting a composition of 99.9% copper, with small amounts of other elements like phosphorus to boost durability. They showcase remarkable thermal and electrical conductivity, along with a tensile strength that ranges from 200 to 400 MPa, depending on the temper. Thanks to copper’s exceptional ductility and malleability, it’s easy to shape and process, while its inherent corrosion resistance ensures long-lasting reliability even in tough environments.
| ASTM Specification | ASTM B152 UNS C12200, ASME SB152, MSRR, AMS, BS |
|---|---|
| Specification | MSRR, AMS, BS, ASTM B152 / ASME SB152 |
| ASTM Standard Designations for C10200 OFHC Copper plate and sheet | ASTM B152 C10100 meets ASTM F68 specification. |
| Length & Sizes | 1000 mm x 2000 mm, 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2m, 2.44m, 3m, 36″ X 120″ or 48″ X 144″, Cut to size available |
| Thickness | 0.1mm to 100 mm Thk |
| Sheet Width | 36” widths – .032”, .0625”, .125” |
| Plate Width | 10-2500mm |
| AMS | AMS |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Temper | Annealed, 1/4-Hard, 1/2-Hard, 3/4-Hard, Full Hard, Hard as Rolled, Spring |
| Condition | Polished on both sides |
| Finish | Bare/Standard, Hot Tin Dipped, Tin Plated, Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Stock in form of | C101 Copper Plate, Sheet, Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling Plate, Flat Shim, Blank (Circle), hot rolled, cold rolled, annealed, soft annealed, descaled, sheared, tread plate, Checker Plate |
| Gauges | .0005″ to .010″ .0005″, .0007″, .001″, .0014″, .002″, .003″, .004″, .005″, .006″, .008″, .010″ |
| Proof Stress | 50 to 340 MPa |
| Tensile Strength | 200 to 360 MPa |
| Hardness | 40 to 110 HV |
| Elongation | 50-5 % |
| Density | 8.92 g/cm³ |
| Melting Point | 1083 °C |
| Thermal Expansion | 16.9 x10^-6 /K |
| Modulus of Elasticity | 117 GPa |
| Thermal Conductivity | 391.1 W/m.K |
| Electrical Resistivity | 0.0203 x10^-6 Ω .m |
| Machinability | Average |
| Workability – Cold | Excellent |
| Weldability – Gas | Good |
| Weldability – Arc | Not recommended |
| Weldability – Resistance | Not recommended |
| Brazeability | Excellent |
| Copper profiling | To provide a full profiling service we use numerous profiling methods including:
|
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| THICKNESS | 4’X 2′ | 2M X 1M | 2500MM X 12500MM |
|---|---|---|---|
| Size | Weight per sheet in Kg | ||
| 0.35 | 2.37 | ||
| 0.4 | 2.68 | 7.14 | |
| 0.45 | 2.99 | 8.04 | |
| 0.5 | 3.3 | 8.93 | |
| 0.55 | 3.61 | 9.8 | |
| 0.6 | 3.92 | 10.72 | |
| 0.7 | 4.64 | 12.5 | |
| 0.8 | 5.3 | 14.29 | |
| 0.9 | 6.0 | 16.07 | |
| 1.0 | 6.6 | 17.86 | |
| 1.2 | 7.9 | 21.43 | 34 |
| 1.4 | 9.3 | ||
| 1.6 | 10.6 | 28.56 | 45 |
| 2.0 | 13.3 | 35.72 | 56 |
| 2.5 | 16.5 | 44.65 | 70 |
| 3.0 | 19.9 | 53.58 | 84 |
| 3.25 | 21.6 | 58.05 | 91 |
| 4.0 | 26.5 | 71.44 | 112 |
| 4.76 | 32.3 | 85.0 | 133 |
| 5.0 | 33.1 | 89.3 | 140 |
| 6.0 | 39.8 | 107.16 | 168 |
| 6.35 | 42.2 | 113.4 | 177 |
| 8.0 | 54 | 224 | |
| 9.525 | 64 | 266 | |
| 10.0 | 279 | ||
| 12.0 | 215 | 335 | |
| 12.7 | 227 | ||
| 15.8 | 283 | ||
| 16.0 | 268 | ||
| 19.0 | 340 | ||
| 20.0 | 358 | ||
| 22.0 | 393 | ||
| 25.0 | 447 | ||
| 30.0 | 536 | ||
| 40.0 | 715 | ||
| 45.0 | 804 | ||
| 50.0 | 893 | ||
| 75.0 | 1340 | ||
| 100.0 | 1787 | ||
| 150.0 | 2680 | ||
Copper sheets and plates offer many advantages including excellent electrical and thermal conductivity, making them ideal for electrical and heat transfer applications They are highly corrosion resistant, ensuring durability last longer in harsh environments, and have excellent formability, making them easier to assemble and manufacture. Copper’s ductility allows for stronger materials, while its non-magnetic properties enhance the efficiency of electrical systems. The material also exhibits high fatigue resistance, providing long-lasting performance. In addition, lead is recyclable, making it environmentally friendly. These properties make copper sheets and plates valuable in industries such as electronics, manufacturing and construction.
Copper Sheets and Plates are incredibly versatile materials, finding their way into a multitude of applications. In Delhi and across India, they are frequently utilized in the electrical sector for busbars, transformers, and circuit components, thanks to their superb conductivity. In the construction realm, they serve purposes like roofing, cladding, and decorative features. Their resistance to corrosion makes them ideal for marine and chemical processing equipment. Moreover, copper sheets and plates are also employed in heat exchangers, cookware, and artistic endeavors, providing durability, visual appeal, and functionality across various industries.
