With its main office located in Hyderabad, India, Daksh Sheets and Plates is a leading producer and supplier of Duplex Steel Sheets and Plates, providing unparalleled quality and engineering accuracy. Our Duplex Steel products are manufactured to meet the rigorous requirements of the oil and gas, petrochemical, marine, and industrial sectors and are renowned for their exceptional strength, resistance to corrosion, and long-term durability. Our sheets and plates are made to international standards and perform at their best in high-pressure and corrosive conditions. Daksh Sheets and Plates is a well-known brand in India and abroad thanks to its unwavering dedication to quality, creativity, and prompt delivery.
The balanced microstructure of austenite and ferrite in duplex steel sheets and plates improves their mechanical and corrosion-resistant qualities. For added strength and resistance, the alloy usually contains 22–25% chromium, 4–6% nickel, 3–4% molybdenum, and nitrogen. These materials have yield strength of about 450 MPa and tensile strength of 620–850 MPa, which is roughly double that of traditional stainless steels. The duplex structure is perfect for demanding applications in harsh environments because it offers exceptional toughness, ductility, and superior resistance to pitting, crevice corrosion, and stress corrosion cracking.
| Specifications | ASTM A240 / ASME SA 240 |
| Duplex Steel Plate Grades | 2205, 2507 |
| Size | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Thickness | 0.1mm to 12 mm Thk |
| Width | 10-2500mm |
| Length | 2m,2.44m, 3m as per requirement |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish | Cold rolled sheet (CR), Hot rolled plate (HR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| MN | C | SI | S | P | CR | NI | MO | N |
|---|---|---|---|---|---|---|---|---|
| 2.0 max | 0.03 max | 1.0 max | 0.02 max | 0.03 max | min: 21.0 max: 23.0 | min: 4.5 max: 6.5 | min: 2.5 max: 3.5 | min: 0.08 max: 0.20 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Duplex Steel Sheets and Plates offer numerous advantages, including superior strength, high resistance to corrosion, and exceptional durability in aggressive environments. The combination of austenitic and ferritic microstructures provides enhanced resistance to stress corrosion cracking, pitting, and crevice corrosion. They are known for their high tensile strength, which makes them ideal for high-pressure and high-temperature applications. Additionally, Duplex Steel offers excellent weldability and formability, making it suitable for a wide range of industries, including oil and gas, chemical, marine, and structural applications. Its cost-effectiveness further adds to its appeal.
| Thickness (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) |
| 5 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 6 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 8 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 10 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 12 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 15 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 16 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 20 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 25 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 30 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 35 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 40 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 45 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 50 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 60 | 4000 x 2000 | ||||
| 70 | 4000 x 2000 | ||||
| 80 | 4000 x 2000 | ||||
| 90 | 4000 x 2000 | ||||
| 100 | 4000 x 2000 |
| Surface finish | Thickness (mm) | Width (mm) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed | 0.25–8.0 | max. 2032 |
| 2D – Cold rolled, heat treated, pickled | 0.4–6.35 | max. 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled | 0.4–8.0 | max. 2032 |
| 2R – Cold rolled, bright annealed | 0.25–3.5 | max. 1524 |
| 2H – Work hardened | 0.4–6.35 | max. 1524 |
| Polished, brushed | 0.5–4.0 | max. 1524 |
Duplex steel plates and sheets are widely used in industries that demand exceptional corrosion resistance and strength. They are perfect for pipelines, separators, heat exchangers, and offshore platforms in the oil and gas industry. They are used in storage tanks, pressure vessels, and reactors in the chemical and petrochemical industries where resistance to harsh chemicals and acids is essential. Because of its resistance to saltwater, Duplex Steel is a great choice for shipbuilding, desalination plants, and subsea structures in the maritime sector. Power plants, building frameworks, and food processing facilities are among the other uses for this material, which offers durability, performance, and cost effectiveness.
