With its main office in Hyderabad, India, Daksh Sheets and Plates is a well-known producer and supplier of high-end metal products designed to satisfy the various needs of industrial sectors. Duplex Steel S32205 Sheets and Plates, which are renowned for their exceptional strength, exceptional resistance to corrosion, and long-term durability, are among the many materials in which we specialize. Offering dependable and high-performance materials for crucial operations, Daksh Sheets and Plates is a trusted partner for industries like chemical processing, marine applications, and oil & gas infrastructure. The company places a strong emphasis on precision engineering, timely delivery, and cost-effective solutions.
About 22–23% chromium, 5–6% nickel, 3% molybdenum, and trace elements like manganese, carbon, and nitrogen make up Duplex Steel S32205, a nitrogen-enhanced duplex stainless steel. Excellent corrosion resistance and high mechanical strength are provided by this well-balanced austenitic-ferritic structure. Excellent performance in challenging conditions is ensured by the material’s 450–620 MPa yield strength, 680–860 MPa tensile strength, and 25–40% elongation. Because of its resistance to pitting, crevice corrosion, and stress corrosion cracking caused by chloride, S32205 is perfect for harsh industrial and marine environments.
| Specification | ASTM A 815, ASME SA 815, ASTM A 182, ASME SA 182 |
| Type | Seamless / Welded / Fabricated |
| Range | ½”NB to 24″NB in Sch 10S, 40S, 80S, 160s, XXS |
| Dimensions | ANSI/ASME B16.9, B16.28, MSS-SP-43 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32205 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 21.0 – 23.0 | 2.50 – 3.50 | 4.50 – 6.50 | 0.8 – 0.20 | 63.54 min |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| S32205 | 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 116000 , MPa – 800 | Psi – 80000 , MPa – 550 | 15 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Duplex Steel Sheet and Plates S32205 offer a combination of high strength and excellent corrosion resistance, making them ideal for harsh environments. Their balanced microstructure of austenite and ferrite enhances resistance to stress corrosion cracking, pitting, and crevice corrosion. With superior mechanical properties, including high tensile strength and yield strength, S32205 is highly durable and reliable. These plates also offer excellent weldability and formability, making them versatile for various industrial applications such as chemical processing, offshore, and marine industries. They provide a cost-effective alternative to more expensive high-alloy steels in demanding conditions.
Yes, we offer custom sizes for Duplex Steel Sheet and Plates S32205 to meet specific project needs. Our team at Daksh Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@dakshsheetsandplates.co.in
| Duplex 2205 | UNS S31803 | 1.4462 | F51 |
| Thickness (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) |
| 5 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 6 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 8 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 10 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 12 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 15 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 16 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 20 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 25 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 30 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 35 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 40 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 45 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 50 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 60 | 4000 x 2000 | ||||
| 70 | 4000 x 2000 | ||||
| 80 | 4000 x 2000 | ||||
| 90 | 4000 x 2000 | ||||
| 100 | 4000 x 2000 |
| Surface finish | Thickness (mm) | Width (mm) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed | 0.25–8.0 | max. 2032 |
| 2D – Cold rolled, heat treated, pickled | 0.4–6.35 | max. 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled | 0.4–8.0 | max. 2032 |
| 2R – Cold rolled, bright annealed | 0.25–3.5 | max. 1524 |
| 2H – Work hardened | 0.4–6.35 | max. 1524 |
| Polished, brushed | 0.5–4.0 | max. 1524 |
Industries that demand high strength, resistance to corrosion, and extended service life frequently use Duplex Steel S32205 Sheets and Plates. Heat exchangers, pressure vessels, storage tanks, and piping systems in chemical plants, oil and gas refineries, and offshore platforms are examples of typical applications. Because of its resistance to seawater corrosion, the material is also perfect for marine environments, including shipbuilding and desalination plants. S32205 is also used in power plants, pulp and paper mills, and buildings that are subjected to severe weather. It is a favored option for demanding applications due to its adaptability, robustness, and low maintenance requirements.
