Based in Delhi, India, Daksh Sheets and Plates is a reputable manufacturer and supplier of EN9 Sheets and Plates. Daksh, which specialises in premium carbon steel products, provides EN9 sheets and plates that adhere to strict industrial requirements. These sheets are well-known for their superior mechanical strength, dimensional accuracy, and surface finish, making them perfect for a variety of structural and engineering uses. Every product from Daksh is guaranteed to last and perform well thanks to sophisticated manufacturing techniques and stringent quality control. Daksh, which serves customers all over India, is dedicated to offering dependable steel solutions for the fabrication, machinery, construction, and automotive sectors.
Medium carbon steel EN9 Sheets and Plates contain between 0.50 and 0.60 percent carbon, 0.50 and 0.8 percent manganese, and trace amounts of silicon, sulphur, and phosphorous. EN9 plates have a tensile strength of approximately 600–800 MPa and are well-known for their high tensile strength and resistance to wear. They can be heat-treated to increase their strength and show good machinability. EN9 is appropriate for medium-duty mechanical components because it offers moderate ductility and impact resistance. Depending on the finish and heat treatment conditions, its Brinell Hardness can range from 180 to 240 HB.
| Thickness | from 3mm up to as thick as 150mm |
|---|---|
| Size | from 2000 x 1000mm up to 4000 x 2000mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | -52° C |
| Process of Manufacturing | Hot-Rolled (HR) |
| Grade | Cr | C | Ni | Si | S | Mn | P | Mo |
| EN – 9 | – | .50 – .60 | – | .05 – .35 | .040 MAX | .50 – .80 | .040 MAX | – |
| Heat Treatment | Condition Tons/SQ.inch | Tensile Stress RE MPA | RP0.2 MPA | A min on 5.65so | Impac | Hardness HB | Limited Ruling Section mm | |
| IZODFT.L.b | KCV Joules | |||||||
| Normalise | 45 | 700 | – | 12 | – | – | 201-255 | 63 |
| 39 | 600 | – | 13 | – | – | 170/223 | 250 | |
| R | 45/55 | 700/850 | 385 | 14 | – | – | 201/277 | 100 |
| S | 50/60 | 775/925 | 450 | 14 | – | – | 223/277 | 63 |
| T | 55/65 | 850/1000 | 555 | 12 | – | – | 248/302 | 19 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Daksh Sheets and Plates based in Hyderabad , India, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Yes, we offer custom sizes for EN 9 Sheet and Plates to meet specific project needs. Our team at Daksh Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@dakshsheetsandplates.co.in
Applications needing greater strength and durability than mild steel frequently use EN9 Sheets and Plates. Because of their exceptional resistance to wear, they are frequently used in the production of automotive parts like crankshafts, shafts, sprockets, and gears. EN9 is utilised for general engineering components, tools, dies, and structural parts in the machinery and construction industries. It is also appropriate for medium-stress mechanical components that need to be machinable and tough. Because of its versatility in heat treatment, the steel is perfect for precision parts where long-term performance depends on both strength and dimensional stability.
