Serving a broad range of industrial sectors, Daksh Sheets and Plates, a leading manufacturer and supplier of premium metal sheets and plates, is based in Hyderabad, India. The company provides specialized products such as Hastelloy B2 Sheets and Plates, which are made to function in extremely corrosive environments, with a strong emphasis on precision engineering and durability. These sheets and plates are perfect for use in chemical processing, pharmaceuticals, and pollution control systems because of their exceptional resistance to hydrochloric acid and other harsh chemicals. For crucial industrial needs, Daksh guarantees dependable solutions with premium quality, affordable prices, and on-time delivery.
About 60–63% nickel, 28–30% molybdenum, and 2-3% iron make up Hastelloy B2 Sheets and Plates, with trace amounts of carbon, manganese, silicon, and cobalt. The alloy has exceptional resistance to reducing agents like sulfuric acid, hydrochloric acid, and other harsh chemicals because of its chemical composition. Excellent formability, toughness, and strength are provided by the mechanical properties, which include tensile strength of 480–620 MPa, yield strength of 205–345 MPa, and elongation of 30–45%. These qualities guarantee stability and long-lasting performance in harsh chemical and thermal environments.
| Type | Plate, Sheet, Strip, Coils, Foils, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate |
|---|---|
| Grade | ASME SB333, ASTM B333 UNS N10665, ASTM B333 UNS N010675, AMS, MSRR, BS |
| Length | 0-12mm or as required |
| Specification of ASTM B333 Alloy B2 Plate | ASTM B333 UNS N10665, ASME SB333, MSRR, BS, AMS 4544 sheet |
| Alloy B2 Plate Width | 0-2500mm or as required |
| UNS N10665 Plate Thickness | 0.3 to 1200 mm or as required |
| Plate Process | Hot/ Cold Rolled |
| Plate surface | No.1, No. 2D, No. 2B, BA, No.3, No.4, No.6, No.7, 2B, 2D, BA NO(8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled ASTM B333 Alloy B2 Plate, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Alloy B2 | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr |
| Balance | 0.02 max | 26 – 30 | 1.00 max | 0.1 max | 2.0 max | 0.04 max | 0.03 max | 1.0 max | 1.0 max |
| Grade | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| Alloy B2 | 9.2 g/cm3 | 1370 °C (2500 °F) | Psi – 51000 , MPa – 350 | Psi – 1,10,000 , MPa – 760 | 40 % |
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Alloy B2 | N10665 | 2.4617 | – | – | – | – | – |
|
Stocked Sizes |
|
|---|---|
|
Size (in inches) |
Size (in mm) |
|
.125″ |
3.18mm |
|
.134″ |
3.40mm |
|
.156″ |
3.96mm |
|
.187″ |
4.75mm |
|
.250″ |
6.35mm |
|
.312″ |
7.92mm |
|
.375″ |
9.53mm |
|
.500″ |
12.7mm |
|
.600″ |
15.9mm |
|
.750″ |
19.1mm |
|
.875″ |
22.2mm |
|
1″ |
25.4mm |
|
1.125″ |
28.6mm |
|
1.250″ |
31.8mm |
|
1.500″ |
38.1mm |
|
1.750″ |
44.5mm |
|
2″ |
50.8mm |
|
2.500″ |
63.5mm |
|
3″ |
76.2mm |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Hastelloy B2 sheets and plates offer exceptional advantages particularly in highly corrosive environments. Known for their superior resistance to hydrochloric acid, sulfuric acid, and other aggressive chemicals, they are ideal for chemical processing, storage, and handling systems. Their high strength and excellent resistance to pitting, crevice corrosion, and stress corrosion cracking ensure long-lasting performance. Additionally, Hastelloy B2 provides outstanding weldability and formability making it easy to fabricate for complex applications. Its ability to maintain structural integrity under extreme conditions reduces maintenance and downtime, enhancing operational efficiency in industries such as pharmaceuticals, chemical and petrochemical.
| Thickness | Plate Weight per Unit Area | Density |
|---|---|---|
| 3/16 inches | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/4 inches | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/8 inches | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/2 inches | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 5/8 inches | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/4 inches | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 7/8 inches | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 inches | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/4 inches | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/2 inches | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 3/4 inches | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 inches | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/4 inches | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/2 inches | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 3/4 inches | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3 inches | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
Applications requiring remarkable resistance to powerful chemical attacks make extensive use of Hastelloy B2 Sheets and Plates. They are used in reactors, heat exchangers, distillation columns, and storage tanks in the chemical processing industry, particularly in the presence of sulfuric or hydrochloric acid. This alloy is used in the petrochemical and pharmaceutical industries for parts that require strong corrosion resistance in sterile and reactive environments. Hastelloy B2 is also essential for long-term durability against acidic gases and liquids in waste treatment facilities, pollution control systems, and flue gas desulfurization units. In mission-critical situations, its strong performance guarantees dependability and safety.
