Premium-grade Hastelloy C22 Coils and Slitting Coils, perfect for use in highly corrosive and hot conditions, are the speciality of Daksh Sheets and Plates, a well-known manufacturer and supplier with headquarters in Delhi, India. Modern technology and premium raw materials are used in the production of these coils to guarantee accuracy, robustness, and adherence to international standards. Our Hastelloy C22 coils, which come in a variety of custom widths, thicknesses, and finishes, are renowned for their outstanding mechanical qualities and remarkable resistance to chemical attack. For reliable solutions in chemical processing, marine engineering, power generation, and pollution control systems, industries all over the world rely on Daksh Sheets and Plates.
Hastelloy C22 Slitting/Coils In addition to iron, cobalt, and trace amounts of manganese, coils are made up of roughly 56% nickel, 20–22.5% chromium, 12.5–14.5% molybdenum, and 2.5–3.5% tungsten. Excellent resistance to oxidising and reducing agents, such as ferric chlorides, nitric acid, and wet chlorine, is offered by this alloy. The material has outstanding ductility, toughness, and a high tensile strength of about 100 ksi. Hastelloy C22 coils are perfect for demanding industrial settings because they have outstanding resistance to pitting, crevice corrosion, and stress-corrosion cracking, as well as the ability to maintain mechanical integrity at high temperatures.
| Specifications | ASTM / ASME SB575 |
| Size | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Thickness | 0.1mm to 12 mm Thk |
| Form | Coils, Foils, Rolls, Plain Coils, Shim Coils, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish | Hot rolled Coils (HR), Cold rolled Coils (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| C22 | 0.010 max | 0.50 max | 0.08 max | 0.02 max | 2.50 max | 50.015 min* | 20.00 – 22.50 | 2.00 – 6.00 | 12.50 – 14.50 | 0.02 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C22 | 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
| STANDARD | UNS | WNR. | JIS | GOST | EN | OR |
| Hastelloy C22 | N06022 | 2.4602 | NW 6022 | – | NiCr21Mo14W | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Daksh Sheets and Plates based in Hyderabad , India, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Coil/Coil Type | Sizes | Availability |
|---|---|---|
| ASTM B575 Hastelloy C22 Coil | 0.4mm | √ |
| ASTM B575 Hastelloy C22 Coil | 0.5mm | √ |
| ASTM B575 Hastelloy C22 Coil | 0.8mm | √ |
| ASTM B575 Hastelloy C22 Coil | 1mm | √ |
| ASTM B575 Hastelloy C22 Coil | 1.2mm | √ |
| ASTM B575 Hastelloy C22 Coil | 1.6mm | √ |
| ASTM B575 Hastelloy C22 Coil | 2mm | √ |
| ASTM B575 Hastelloy C22 Coil | 3mm | √ |
| ASTM B575 Hastelloy C22 Coil | 4mm | √ |
| Hastelloy C22 ASTM B575 Coil | 5mm | √ |
| ASTM B575 Hastelloy C22 Coil | 6mm | √ |
| ASTM B575 Hastelloy C22 Coil | 8mm | √ |
| ASTM B575 Hastelloy C22 Coil | 10mm | √ |
| ASTM B575 Hastelloy C22 Coil | 12mm | √ |
| ASTM B575 Hastelloy C22 Coil | 16mm | √ |
| ASTM B575 Hastelloy C22 Coil | 20mm | √ |
| ASTM B575 Hastelloy C22 Coil | 25mm | √ |
| Steel Coil | Size (mm) | Weight per Coil (Kg) | Size(mm) | Weight per Coil (Kg) |
|---|---|---|---|---|
| Hastelloy C22 Coil | 4000 x 2000 x 2.0 | 136.0 | 3000 x 1500 x 5.0 | 191.0 |
| Hastelloy C22 Coil | 4000 x 2000 x 3.0 | 204.0 | 4000 x 2000 x 5.0 | 340.0 |
| Hastelloy C22 Coil | 2500 x 1250 x 4.0 | 106.0 | 2500 x 1250 x 6.0 | 159.0 |
| Hastelloy C22 Coil | 3000 x 1500 x 4.0 | 153.0 | 3000 x 1500 x 6.0 | 230.0 |
| Hastelloy C22 Coil | 4000 x 2000 x 4.0 | 272.0 | 4000 x 2000 x 6.0 | 408.0 |
| Hastelloy C22 Coil | 2500 x 1250 x 5.0 | 133.0 |
Yes, we offer custom sizes for Hastelloy C22 Coil/Slitting Coil to meet specific project needs. Our team at Daksh Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@dakshsheetsandplates.co.in
Hastelloy C22 Slitting/Coils Industries that require strong corrosion resistance and structural dependability frequently use coils. They are employed in the chemical processing industry to fabricate storage tanks, reactors, heat exchangers, and pipelines that handle aggressive media. These coils are essential for contamination-free processing equipment in the food and pharmaceutical industries. Seawater piping and parts exposed to chloride-rich environments are examples of marine applications. Hastelloy C22 coils are used in heat recovery and flue gas scrubbers at power plants. They are also appropriate for high-purity, aerospace, and pollution control applications due to their exceptional resistance to thermal stress and chemical attack.
