One of Delhi, India’s top producers and suppliers of high-performance Haynes 25 Foil is Daksh Sheets and Plates. Our precision-engineered Haynes 25 Foil, which specialises in advanced alloys for harsh environments, satisfies the exacting requirements of the chemical processing, power generation, and aerospace industries. We provide materials with exceptional strength, thermal stability, and oxidation resistance, and we are well-known for our dedication to quality. Our foils are produced in accordance with international standards, guaranteeing reliable performance even in the face of extreme heat and stress. At Daksh, we support vital applications throughout India and beyond by fusing technical know-how with effective service.
The primary alloying elements of Haynes 25 Foil, a cobalt-based superalloy, are cobalt (about 52%), chromium (about 20%), tungsten (about 15%), and nickel (about 10%). At temperatures as high as 980°C, this composition provides exceptional strength and resistance to oxidation. Mechanically, Haynes 25 has a high tensile strength (up to about 1240 MPa) and good ductility, which allows it to form into thin foils without breaking. Under thermal cycling, it continues to exhibit outstanding resistance to creep and fatigue. For crucial, heat-resistant applications, the alloy is a preferred material due to its stability at high temperatures.
| Standard | AMS 5759, AMS 5537 |
| Dimensions : | AMS, AMS, API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat |
| Grade | C% | Si≤ % | Mn≤ % | P≤ % | S≤ % | Cr% | Ni% | Co% | Fe % | W % |
| Haynes 25 / L605 | 0.05-0.15 | 0.40 | 2.00 | 0.02 | 0.015 | 19.0-21.0 | 9.00-11.0 | Rest | ≤ 3.00 | 14.0-16.0 |
| Grade | 0.2% Yield strength Rp ≥ N/mm² | Tensile strength Rm N/mm² | Elongation A5 | Resistant on air up to°C | Modulus of elasticity kN/mm² |
| Haynes 25 / L605 | 345 | 830-1130 | 25 | 1090 | 225 |
| STANDARD | Material No | EN Designation | UNS | Alloy |
| Haynes 25 / L605 | 2.4964 | CoCr20W15Ni | R30605 | 25 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Because of its exceptional strength and resistance to oxidation, Haynes 25 Foil is frequently utilised in high-temperature, high-stress settings. It is mostly used in the aerospace sector for parts like turbine engine liners, afterburner components, and combustion chambers. It is used in industrial furnaces and gas turbines in the power generation industry. Equipment used in chemical processing that is subjected to oxidative and corrosive conditions can also benefit from Haynes 25 Foil. Its thin, flexible shape makes it suitable for applications where temperature endurance and durability are crucial, such as heat shields, sealing materials, and insulating wraps.
