Located in Delhi, India, Daksh Sheets and Plates is a well-known manufacturer and supplier of premium-grade Monel 400 Circles that are made to satisfy the exacting requirements of different industrial sectors. Daksh’s Monel 400 Circles are well-known for their precision engineering, robustness, and ability to withstand harsh conditions. They are perfect for use in power generation, chemical, oil and gas, and marine applications. The business prioritises high-quality manufacturing while utilising cutting-edge equipment and abiding by global standards. Daksh Sheets and Plates has established a solid reputation in the industry for high-performance nickel alloy solutions thanks to its robust distribution network, prompt delivery, and customer-focused approach.
The main constituents of Monel 400 Circle, a solid-solution nickel-copper alloy, are nickel (63% min) and copper (28%–34%), with trace amounts of iron, manganese, carbon, and silicon. It provides exceptional resistance to corrosion, particularly in chemical and saltwater environments. Tensile strength of 480–620 MPa, yield strength of approximately 170 MPa, and elongation of up to 35% are examples of mechanical properties. Monel 400 is dependable for crucial industrial processes because it maintains its toughness over a broad temperature range and is renowned for its excellent weldability, thermal conductivity, and resistance to stress corrosion cracking.
| Standard | ASTM B127, ASME SB127 |
| Dimensions | ASTM, ASME and API |
| Standard | JIS, AISI, ASTM, GB, DIN, EN, etc. |
| Thickness | 1 Mm To 100 mm. |
| Diameter | Upto 2000 Mm. |
| Circle Diameter | 3″ DIA up to 38″ DIA 1500 lbs max. |
| Circles Form | Cold Rolled, Small Flat, Industrial, Proof Machined, Perforated, Forged Steel, Hot Rolled Circle. |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | Ni | C | Al | Mn | Si | Fe | Cu | S |
| Monel 400 | 63.0 min | 0.3 max | 0.50 max | 2.0 max | 0.5 max | 1.0 – 2.5 | 28.0 – 34.0 | 0.02 max |
| Property | Value |
|---|---|
| Tensile Strength | 70-95 ksi (485-655 MPa) |
| Yield Strength | 30 ksi (205 MPa) min |
| Elongation | 35% min in 2 inches (50 mm) |
| Hardness | Rockwell B70 max |
| Modulus of Elasticity | 28 x 106 psi (193 GPa) |
| Poisson’s Ratio | 0.31 |
Yes, we offer custom sizes for Monel 400 Circle to meet specific project needs. Our team at Daksh Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@dakshsheetsandplates.co.in
| Outer Diameter (OD) (mm) | Thickness (mm) | Size (mm) | Approximate Weight (kg) |
|---|---|---|---|
| 100 | 5 | 100 x 5 | 3.92 |
| 150 | 10 | 150 x 10 | 17.66 |
| 200 | 15 | 200 x 15 | 39.26 |
| 250 | 20 | 250 x 20 | 68.83 |
| 300 | 25 | 300 x 25 | 107.36 |
| 350 | 30 | 350 x 30 | 154.87 |
| 400 | 35 | 400 x 35 | 211.35 |
| 450 | 40 | 450 x 40 | 276.80 |
| 500 | 50 | 500 x 50 | 392.70 |
| Property | Value |
|---|---|
| Density | 8.80 g/cm³ |
| Melting Point | 1,455°C (2,651°F) |
| Electrical Resistivity | 0.49 µΩ·cm |
| Thermal Conductivity | 35.4 W/m·K |
| Thermal Expansion (25-100°C) | 13.4 µm/m·K |
| Specific Heat (at 25°C) | 0.385 J/g·K |
| Young’s Modulus | 193 GPa (28 x 10⁶ psi) |
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
|---|---|---|---|---|---|---|---|
| Monel 400 | N04400 | 2.4360 | NU-30M | NiCu30Fe | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 |
Monel 400 Circles are frequently utilised in settings where strength and resistance to corrosion are crucial. Because of their exceptional resistance to saltwater and biofouling, they are used in heat exchangers, pump shafts, and seawater valves in maritime applications. They are utilised in piping systems that handle acidic and alkaline solutions, process vessels, and storage tanks in the chemical industry. They are used in condensers, offshore platforms, and refinery equipment in the oil and gas industry. Additionally, Monel 400 is used in aerospace parts, power plants, and medical devices where non-magnetic, heat-resistant, and long-lasting qualities are essential.
