Based in Delhi, India, Daksh Sheets and Plates is a well-known producer and supplier of high-grade Monel 400 Foils, serving sectors that require materials with high strength and resistance to corrosion. Daksh manufactures Monel 400 Foils that satisfy international quality standards and is renowned for their dedication to accuracy, dependability, and prompt delivery. For industrial, chemical, marine, and aerospace applications where resistance to harsh environments is crucial, these foils are perfect. Daksh is a reputable brand in speciality alloy solutions because of their cutting-edge manufacturing facilities, team of knowledgeable experts, and commitment to consistent product performance, customised dimensions, and affordable prices.
The main constituents of Monel 400 Foil, a solid-solution nickel-copper alloy, are nickel (63% min) and copper (28%–34%), with trace amounts of iron, manganese, silicon, and carbon. Excellent resistance to alkalis, acids, steam, and seawater is provided by the alloy. It has an elongation of up to 35%, a yield strength of about 170 MPa, and a tensile strength of 480–620 MPa. Because Monel 400 is extremely ductile, has good weldability, thermal conductivity, and maintains its mechanical qualities over a broad temperature range, it can be used in difficult-to-weld situations.
| Standards | ASTM B127 / ASME SB127 |
| Thickness | 0.3 – 10.0mm & AS PER CUSTOMER’S REQUIREMENT |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm & AS PER CUSTOMER’S REQUIREMENT. |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm & AS PER CUSTOMER’S REQUIREMENT. |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard AS PER CUSTOMER’S REQUIREMENT. |
| Test Certificate | Chemical test, Fitting test, Alloy test, Radiography test, Macro and micro-test, Hydrostatic test, Impact test. |
| Finish | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled (HR), Cold rolled (CR), SATIN (Met with Plastic Coated) etc. |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Monel 400 | 2.4360 | N04400 | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 | NU-30M | NiCu30Fe |
Many industries that need thin, corrosion-resistant materials use Monel 400 Foils. Because of their resistance to moisture and seawater, they are utilised in the marine industry for protective linings, seals, and insulating layers. Monel 400 Foils are used in chemical processing as gaskets, liners, and barriers in corrosive conditions. They are used in instrumentation, shielding, and structural reinforcements in the aerospace and defence sectors. They are used in flexible connectors, condenser tubes, and heat exchangers in the oil and gas industry. They are also appropriate for high-performance industrial equipment, electronics, and medical devices due to their toughness and formability.
