High-performance Monel K500 Channels for a variety of industrial applications are the speciality of Delhi, India-based Daksh Sheets and Plates, a well-known manufacturer and supplier. Daksh is renowned for their dedication to quality, accuracy, and client satisfaction. They provide high-strength, corrosion-resistant products that satisfy international standards. To function under the most demanding circumstances, Monel K500 Channels are designed with premium-grade raw materials and cutting-edge fabrication techniques. These channels, which are supported by strict quality checks and prompt delivery, are perfect for the chemical processing, oil and gas, marine, and aerospace industries. For high-end alloy solutions, Daksh is a reliable partner.
Through age-hardening, titanium (0.35–0.85%) and aluminium (2.3–3.15%) are added to strengthen the nickel-copper alloy known as Monel K500 Channel. Nickel (63% min) and copper (27–33%) make up the base composition, with trace amounts of carbon, manganese, and iron. With a tensile strength of up to 1100 MPa, a yield strength of about 790 MPa, and an elongation of roughly 20%, this alloy demonstrates exceptional mechanical strength. Monel K500 is appropriate for harsh and delicate environments because it maintains its high strength over a wide temperature range, provides exceptional corrosion resistance, and is non-magnetic when annealed.
| Specifications | : | ASTM B865 / ASME B865 |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Monel 400 Channel | : | 40mm*20mm~300mm*300mm |
| Thickness | : | 3.0mm – 120mm |
| Length | : | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | : | C Channel, U Channel, Channels |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | C | Mn | Si | Cu | Fe | Ni | S |
| Monel K500 | 0.25 max | 1.50 max | 0.5 max | 27.0-33.0 | 0.5 – 2 | 63.0 min | 0.010 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 1,60,000 , MPa – 1100 | Psi – 1,15000 , MPa –790 | 20% |
Yes, we offer custom sizes for Monel K500 Channel to meet specific project needs. Our team at Daksh Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@dakshsheetsandplates.co.in
| STANDARD | WERKSTOFF NR. | UNS |
| Monel K500 | 2.4375 | N05500 |
Applications needing extraordinary strength, durability, and resistance to corrosion are best suited for Monel K500 Channels. Because they are resistant to biofouling and seawater corrosion, they are utilised in the marine industry in structural frames, pump shafts, and underwater fasteners. They are used in the oil and gas industry in drill collars, wellhead parts and valves that are subjected to corrosive fluids and high pressure. Engine and landing gear components are examples of aerospace applications. Chemical processing facilities also use Monel K500 for structural reinforcements and piping supports. It is appropriate for sensitive instrumentation and defence systems due to its non-magnetic characteristics.
