For industries needing a special blend of strength and corrosion resistance, Daksh Sheets and Plates, a well-known manufacturer and supplier in Delhi, India, provides high-performance Monel K500 Foils. Our Monel K500 foils are made with premium raw materials and state-of-the-art manufacturing techniques, and they have outstanding thermal stability, durability, and resistance to sour gas, chemicals, and seawater. These foils come in a range of thicknesses and sizes to meet the needs of different applications. With pride, Daksh Sheets and Plates provides precision-engineered foils that satisfy global quality standards and performance requirements to industries including chemical processing, oil and gas, marine, and aerospace.
The nickel-copper alloys that make up Monel K500 Foils are composed of roughly 63% nickel, 27–33% copper, and the minor but essential additions of titanium (0.35–0.85%) and aluminium (2.3–3.15%). Its precipitation hardening, which gives it more strength than Monel 400, is caused by these alloying elements. Even at high temperatures, Monel K500 foils have exceptional mechanical qualities, such as a high yield strength and a tensile strength of up to 160 ksi. In fast-moving seawater and chemical solutions, they resist stress-corrosion cracking and erosion while maintaining exceptional corrosion resistance in marine and chemical environments.
| Standards | ASTM B127 / ASME SB127 |
| Thickness | 0.3 – 10.0mm & AS PER CUSTOMER’S REQUIREMENT |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm & AS PER CUSTOMER’S REQUIREMENT. |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm & AS PER CUSTOMER’S REQUIREMENT. |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard AS PER CUSTOMER’S REQUIREMENT. |
| Test Certificate | Chemical test, Fitting test, Alloy test, Radiography test, Macro and micro-test, Hydrostatic test, Impact test. |
| Finish | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled (HR), Cold rolled (CR), SATIN (Met with Plastic Coated) etc. |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel K500 | 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20 % |
| STANDARD | WERKSTOFF NR. | UNS | AFNOR | JIS | GOST | BS | EN |
| Monel k500 | 2.4375 | N05500 | – | – | – | – | – |
Many industries use Monel K500 Foils because they need to be strong and resistant to harsh conditions. Because of their exceptional resistance to corrosion, they are utilised in the marine industry for fasteners, pump parts, and seawater valves. These foils are perfect for sour gas applications, sub-sea equipment, and non-magnetic components in the oil and gas sector. High strength-to-weight ratios are required for springs and structural elements used in aerospace applications. Monel K500 foils are used in chemical processing facilities to handle corrosive materials such as hydrofluoric and sulphuric acids. They are also appropriate for heat exchanger components and precision instruments due to their remarkable formability and durability.
