With its main office in Hyderabad, India, Daksh Sheets and Plates is a reputable brand in the production and distribution of high-grade metal sheets and plates. Nickel Alloy 200 Foils are a standout among our specialty products due to their remarkable mechanical strength, high electrical and thermal conductivity, and resistance to corrosion. Our foils provide accuracy and dependability in every application and are made to satisfy the demanding requirements of sectors like chemical processing, marine engineering, and aerospace. Daksh Sheets and Plates is still the go-to partner for advanced material needs in a variety of industrial sectors because of its emphasis on personalized solutions and first-rate service.
About 99.6% pure nickel makes up Nickel Alloy 200 Foils, with trace amounts of carbon, manganese, silicon, sulfur, and iron. Strong mechanical integrity at low and high temperatures is imparted by this composition, along with exceptional corrosion resistance, particularly in alkaline and neutral environments. The alloy has outstanding conductivity, good formability, and high ductility. Its yield strength is between 100 and 150 MPa, its tensile strength is between 380 and 450 MPa, and its elongation is up to 40%. It is especially well-suited for precision and high-temperature applications due to its low thermal expansion coefficient.
Specifications : ASTM B168 / ASME SB168
Size : 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm
Form : Foils, Rolls
Thickness : 0.1mm to 12 mm Thk
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Finish : Hot rolled plates (HR), Cold rolled sheets (CR), 2B, 2D, 2BB, BA, NO8, SATIN (MET with Plastic coated)
Other services : Heat treatment, Annealing, Pickling, Polish, Electroplating, Anodizing, Rolling, Cutting, Forging, etc.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 200 | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel 200 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 200 | 2.4066 | N02200 | NW 2200 | NA 11 | НП-2 | N-100M | Ni 99.2 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nickel Alloy 200 foils offer excellent corrosion resistance, especially in alkalis, acids, and various chemicals, making them ideal for harsh environments. Known for their high thermal and electrical conductivity, these foils are widely used in applications like electrical components and heat exchangers. They possess outstanding mechanical properties, including strength and flexibility, allowing easy fabrication. Additionally, Nickel Alloy 200 foils exhibit good weldability and formability, making them suitable for various industrial applications, including aerospace, chemical processing, and marine environments. Their stability at elevated temperatures further enhances their reliability.
Because of their exceptional strength, ductility, and resistance to corrosive environments, nickel alloy 200 foils are widely used in a variety of industries. They are utilized in heat exchangers exposed to caustic solutions, storage tanks, and reactors in the chemical processing sector. Because of their superior conductivity and low magnetic permeability, these foils are used in the electrical and electronics industries for resistors, battery components, and electromagnetic shielding. Foils are used in engine parts, valves, and sensor housings in the marine and aerospace industries. Long-lasting performance and safety are guaranteed by their dependability in aggressive, high-temperature, and high-stress environments.
