With its headquarters in Hyderabad, India, Daksh Sheets and Plates is a top producer and supplier of premium metal sheets and plates for a variety of industrial uses. Nickel Alloy 200 Sheets and Plates, one of its premium products, are renowned for their exceptional mechanical strength, corrosion resistance, and thermal conductivity. These products are perfect for the chemical processing, marine, power generation, and aerospace industries because they are designed to function well in harsh environments. Daksh provides customized solutions and timely service to satisfy the changing demands of contemporary industry, with a strong emphasis on quality, durability, and customer satisfaction.
Commercially available nickel alloy 200 is 99.6% pure, with trace amounts of carbon, manganese, and iron added to improve formability and mechanical strength. Its exceptional mechanical qualities, which guarantee exceptional ductility and toughness, include a tensile strength of 415 MPa, a yield strength of 103 MPa, and elongation of up to 40%. Extreme environments can benefit from the alloy’s superior thermal and electrical conductivity, magnetic qualities, and resistance to reducing chemicals. In both cryogenic and high temperature settings, nickel 200 retains its structural integrity and is stable over a broad temperature range.
| Specification | ASTM B 906/ASME SB 906, ASME Code Cases 1827 and N-253, SAE/AMS 5540, BS 3072NA14 and 3073NA14, DIN 17750, ISO 6208, EN 10095, MIL-DTL-23228. |
|---|---|
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard |
| standards and approvals |
|
| Plasma profiles | As per customer’s drawings |
| Value added services | Laser cutting, Waterjet cutting, Plasma cutting, Bending and mechanical processing, edge preparation, welding, sawing and shearing. |
| VAS |
|
| Packing | Bundles with waterproof cloth outside or plywood box |
| Test | UT, SGS testing, TUV etc |
| Nickel 200 | Ni | C | Mo | Mn | Si | Fe | P | S | Cu | Cr |
| 99.0 min | 0.15 max | – | 0.35 max | 0.1 max | 0.4 max | – | 0.01 max | 0.25 max | – |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 21500 , MPa – 148 | Psi – 67000 , MPa – 462 | 45 % |
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Nickel 200 | N02200 | 2.4066 | N-100M | Ni 99.2 | NW 2200 | NA 11 | —2 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nickel Alloy 200 sheets and plates offer exceptional corrosion resistance, particularly against alkalis, acids, and other harsh environments. Known for their excellent weldability and formability, they maintain good mechanical properties at low and high temperatures. The alloy exhibits high strength and durability, making it ideal for chemical processing, aerospace, and marine applications. Its excellent thermal and electrical conductivity ensures reliable performance in various industrial applications. Its non-magnetic properties add to its versatility, especially in sensitive equipment.
| Nickel Gauge Width and Length | Weight Lbs. per Sq. Ft. | Estimated Weight per Sheet |
|---|---|---|
| 7 ga. (.1874″) x 48 x 120 | 7.871 | 314.8 |
| 10 ga. (.135″) x 48 x 120 | 5.670 | 226.8 |
| 11 ga. (.120″) x 36 x 120 | 5.040 | 151.2 |
| 11 ga. (.120″) x 48 x 96 | 5.040 | 161.3 |
| 11 ga. (.120″) x 48 x 120 | 5.040 | 201.6 |
| 11 ga. (.120″) x 48 x 144 | 5.040 | 241.9 |
| 11 ga. (.120″) x 60 x 96 | 5.040 | 252.0 |
| 12 ga. (.105″) x 36 x 120 | 4.410 | 132.3 |
| 12 ga. (.105″) x 48 x 120 | 4.410 | 176.4 |
| 12 ga. (.105″) x 60 x 120 | 4.410 | 220.5 |
| 14 ga. (.075″) x 36 x 120 | 3.150 | 94.50 |
| 14 ga. (.075″) x 48 x 120 | 3.150 | 126.0 |
| 16 ga. (.060″) x 36 x 120 | 2.520 | 75.60 |
| 16 ga. (.060″) x 48 x 96 | 2.520 | 80.64 |
| 16 ga. (.060″) x 48 x 120 | 2.520 | 100.8 |
| 16 ga. (.060″) x 60 x 120 | 2.520 | 126.0 |
| 18 ga. (.048″) x 36 x 120 | 2.016 | 60.48 |
| 18 ga. (.048″) x 48 x 120 | 2.016 | 80.64 |
| 20 ga. (.036″) x 36 x 120 | 1.512 | 45.36 |
| 20 ga. (.036″) x 48 x 120 | 1.512 | 60.48 |
| 22 ga. (.030″) x 36 x 120 | 1.260 | 37.80 |
| 22 ga. (.030″) x 48 x 96 | 1.260 | 40.32 |
| 22 ga. (.030″) x 48 x 120 | 1.260 | 50.40 |
| 24 ga. (.024″) x 36 x 120 | 1.008 | 30.24 |
| 24 ga. (.024″) x 48 x 120 | 1.008 | 40.32 |
| 26 ga. (.018″) x 36 x 120 | .7560 | 22.68 |
| 26 ga. (.018″) x 48 x 120 | .7560 | 30.24 |
| 28 ga. (.015″) x 36 x 120 | .6300 | 18.90 |
Applications needing exceptional corrosion resistance and dependable mechanical performance use nickel alloy 200 sheets and plates. They are utilized in heat exchangers, storage tanks, reactors, and piping systems that deal with acidic or caustic solutions in the chemical industry. They are appropriate for use in aerospace structures, marine components, and food processing equipment due to their oxidation resistance and thermal stability. They can also be utilized in battery connections, electroplating systems, and electronic components due to their high electrical conductivity. Nickel 200 plates are a material of choice for long-term industrial reliability due to their consistent performance in high-temperature and corrosive environments.
