Based in Hyderabad, India, Daksh Sheets and Plates is a well-known producer and supplier of high-performance metal products, known for providing long-lasting and precisely engineered solutions. Because of their exceptional mechanical strength, corrosion resistance, and thermal stability, Nickel Alloy 201 Angles stand out among our premium products. These angles provide outstanding dependability in the chemical, marine, aerospace, and power generation industries and are made to be used in extremely demanding industrial settings. We guarantee that our customers always receive materials that precisely match their needs thanks to our unwavering dedication to quality, customization, and on-time delivery.
With trace amounts of carbon, iron, manganese, silicon, and sulfur, Nickel Alloy 201 Angle is a commercially available nickel alloy that contains over 99% nickel. It is appropriate for high-temperature and chemical environments due to its low carbon content (<0.02%), which improves resistance to intergranular corrosion. With a tensile strength of roughly 370 MPa, a yield strength of 100 MPa, and an elongation of up to 40%, the alloy offers exceptional ductility and toughness. In addition, it has exceptional machinability and weldability, as well as high electrical and thermal conductivity, making fabrication simple.
Specifications : ASTM B160 / ASME SB160
Angle Size Range : 20 x 20 mm to 100 x 100 mm
Angles Thickness : 3 to 12 mm (depending on size)
Length : 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 201 | 0.02 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel 201 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 201 | 2.4068 | N02201 | NW 2201 | NA 12 | НП-2 | – | LC-Ni 99 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nickel Alloy 201 Angles offer exceptional corrosion resistance, making them ideal for chemical processing and marine environments. They exhibit excellent thermal and electrical conductivity, ensuring efficiency in heat exchangers and electrical components. Their high strength and toughness provide durability in harsh conditions. Nickel Alloy 201 is highly oxid-resistant, making it suitable for high-temperature applications. Its ease of fabrication and weldability enhance versatility across industries. The alloy’s magnetic and chemical stability also ensures reliable performance in sensitive applications like electronics and food processing, emphasizing cost-effectiveness and long-term durability.
Industries that require mechanical integrity, corrosion resistance, and thermal stability frequently use nickel alloy 201 angles. They can survive harsh conditions with acids, alkalis, and chlorides in chemical processing. They are perfect for power generation, marine, and aerospace infrastructure because of their stability and structural strength. The alloy’s high conductivity and non-reactive nature make it advantageous for the electronics and food processing industries. It is also appropriate for low-temperature applications due to its good performance at cryogenic temperatures. Even under the most taxing operating circumstances, these adaptable parts provide dependable performance.
