Located in Hyderabad, India, Daksh Sheets and Plates is a reputable producer and supplier of high-quality nickel alloy sheets and plates. We serve a broad range of industries, including chemical processing, aerospace, marine, and power generation, and are renowned for our precision engineering, outstanding material quality, and dedication to customer satisfaction. Our nickel alloy products are made especially to be long-lasting, corrosion-resistant, and capable of performing well under harsh circumstances. We are a preferred option in both domestic and international markets because we concentrate on providing dependable and customized solutions that meet the exacting standards needed by contemporary industries.
Nickel (Ni) makes up the majority of nickel alloy sheets and plates, with different amounts of chromium (Cr), iron (Fe), copper (Cu), and molybdenum (Mo) also present. This alloy composition offers outstanding strength at high temperatures, resistance to oxidation, and resistance to corrosion. These sheets have outstanding fatigue resistance, high tensile strength, and superior weldability. Notably, they exhibit exceptional toughness and resistance to stress corrosion cracking, maintaining their mechanical integrity under extreme temperatures. This makes them appropriate for harsh operating environments in a variety of high-performance applications.
| Specification | ASTM B162 UNS N02200, ASME SB162 |
|---|---|
| Sizes | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Thickness | 0.1mm to 100 mm Thk |
| Width | 10-2500mm |
| Length | 2m, 2.44m, 3m, or as required |
| ASTM | ASTM B168 |
| AMS | AMS 5553 |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Stock in form of | Nickel Plate, Sheet, Plain Sheet, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling Plate, Flat Shim, hot rolled, cold rolled, annealed, soft annealed, descaled, sheared, tread plate, Checker Plate |
| Material | JIS: N0, N2, N1, NW2200, NW2201, NW4400, NW5500, NW6002, etc DIN:H-Ni99.96, H-Ni99.95, H-Ni99.92, H-Ni99.90, H-Ni99.5, H-Ni99, etc |
| profiling | To provide a full profiling service we use numerous profiling methods including:
|
| Specialized in |
|
| Grade | C | Mn | Si | S | Fe | Ni | Cu |
| Nickel Alloy 200 | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.40 max | 99.0 min | 0.25 max |
| Nickel Alloy 201 | 0.02 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel 200 / 201 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | AFNOR | EN | GOST |
| Nickel 200 | 2.4066 | N02200 | NW 2200 | NA 11 | N-100M | Ni 99.2 | НП-2 |
| Nickel 201 | 2.4068 | N02201 | NW 2201 | NA 12 | НП-2 | LC-Ni 99 | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nickel Alloy Sheets and Plates offer exceptional corrosion resistance, making them ideal for harsh environments. They exhibit high-temperature strength, ensuring performance under extreme heat. Their durability and toughness contribute to long service life, while excellent oxidation resistance enhances reliability. With superior thermal and electrical conductivity, they support versatile industrial applications. Nickel alloys provide stress corrosion cracking resistance, improving structural integrity. These sheets and plates are versatile for various industries, including aerospace, marine, and chemical processing. Additionally, they are easily fabricated, allowing customization for specific project needs.
| Plate Thickness (mm) | Weight (kg/m) | kg/meter (width 1200mm) | kg/meter (width 1500mm) | kg/meter (width 1800mm) | kg/meter (width 2400mm) |
| 3 | 23.55 | 28.3 | 35.3 | 42.4 | 56.5 |
| 4 | 31.4 | 37.7 | 47.1 | 56.5 | 75.4 |
| 5 | 39.25 | 47.1 | 58.9 | 70.7 | 94.2 |
| 6 | 47.1 | 56.5 | 70.7 | 84.8 | 113 |
| 8 | 62.8 | 75.4 | 94.2 | 113 | 150.7 |
| 10 | 78.5 | 94 | 118 | 141 | 188 |
| 12 | 94.2 | 113 | 141 | 170 | 226 |
| 16 | 125.6 | 151 | 188 | 226 | 301 |
| 20 | 157 | 188 | 236 | 283 | 377 |
| 22 | 172.7 | 207 | 259 | 311 | 415 |
| 25 | 196.25 | 236 | 294 | 353 | 471 |
| 28 | 219.8 | 264 | 330 | 396 | 528 |
| 32 | 251.2 | 301 | 377 | 452 | 603 |
| 36 | 282.6 | 339 | 424 | 509 | 678 |
| 40 | 314 | 377 | 471 | 565 | 754 |
| 45 | 353.25 | 424 | 530 | 636 | 848 |
| 50 | 392.5 | 471 | 589 | 707 | 942 |
| 55 | 431.75 | 518 | 648 | 777 | 1036 |
| 60 | 471 | 565 | 707 | 848 | 1130 |
| 65 | 510 | 612 | 765 | 918 | 1224 |
| 70 | 549.5 | 659 | 824 | 989 | 1319 |
| 75 | 588.75 | 707 | 883 | 1060 | 1413 |
| 80 | 628 | 754 | 942 | 1130 | 1507 |
| 90 | 706.5 | 848 | 1060 | 1272 | 1696 |
| 100 | 785 | 942 | 1178 | 1413 | 1884 |
Because of their dependability, toughness, and ability to withstand harsh conditions, nickel alloy sheets and plates are used extensively in a variety of industries. They are used in storage tanks, heat exchangers, and reactors in the chemical processing industry. They are preferred for components subjected to high stress and corrosive elements in the marine and aerospace industries. They offer long-term performance and resistance to thermal fatigue in power generation, including nuclear and gas turbine plants. They are also utilized in electrical components, food processing equipment, automobile exhaust systems, and oil and gas pipelines, where their durability and structural soundness are essential.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
