With its main office in Hyderabad, India, Daksh Sheets and Plates is a leading producer and supplier of premium metal sheets and plates for use in a range of industrial applications. The SA515 Grade 60/70 Boiler Sheets and Plates, which are designed for exceptional performance in high-temperature and high-pressure settings, are one of our specialty products. Our products are widely trusted for crucial applications in boiler systems, pressure vessels, and power plants because they prioritize strength, durability, and precision engineering. We are dedicated to upholding the highest standards of quality and guaranteeing client satisfaction by delivering products in a dependable and consistent manner.
The carbon steel alloy SA515 Grade 60/70, which is mostly utilized in boilers and pressure vessels, is renowned for its strength and resistance to heat. With optional additions of silicon and copper, its chemical composition consists of up to 0.30% carbon, 0.90–1.30% manganese, and trace amounts of sulfur (≤0.035%) and phosphorus (≤0.035%). While Grade 70 offers tensile strength of up to 483 MPa, Grade 60 offers tensile strength of 379–517 MPa and yield strength of 207 MPa. The material guarantees strength, weldability, and dependable performance in high-temperature operations with an elongation of 20% in 200 mm.
| Grade | : | ASME SA 515 GR.70 / 60 Boiler and Pressure Vessel Steel Plates |
|---|---|---|
| Width | : | 1500mm-3000mm |
| Thickness | : | 3mm-600mm |
| Length | : | 3000mm-11000mm |
| Production | : | Hot-Rolled (HR) |
| Heat Treatment | : | Rolled/Normalised/N+T/Q |
| Grades | C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
| 60 | 0.18 | 0.4 | 0.95/1.50 | 0.015 | 0.008 | 0.02 (Min) | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| 70 | 0.18 | 0.4 | 0.95/1.50 | 0.015 | 0.008 | 0.02 (Min) | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Grades | Tensile strength (ksi) | Yield strength (ksi) | Elongation min, % 200 mm (8 in) | Elongation min, % 50 mm (2 in) |
| 60 | 485-620 (70-90) | 260 (38) | 17 | 21 |
| 70 | 485-620 (70-90) | 260 (38) | 17 | 21 |
| Grades | British Standard | European Norm | ASTM/ASME | DIN |
| 60 | BS1501-161-430A | EN10028 P265GH | A/SA516 – Grade 60 | DIN 17155 HII |
| 70 | BS1501-224-490A/B | EN10028 P355GH | A/SA516 – Grade 70 | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
SA515 Grade 60/70 Boiler Sheet and Plate offer excellent strength, durability, and resistance to high temperatures, making them ideal for boilers and pressure vessels. These plates exhibit good weldability, making them suitable for complex constructions in power generation, petrochemical, and chemical processing industries. They also provide outstanding resistance to oxidation and corrosion in high-pressure environments. With enhanced mechanical properties, SA515 Grade 60/70 ensures long-term performance and safety, making it a reliable choice for critical applications in energy and manufacturing sectors.
Industries that function in high-pressure and high-temperature settings, like power generation, chemical processing, and oil and gas refineries, heavily rely on SA515 Grade 60/70 Boiler Sheets and Plates. Pressure vessels, boilers, heat exchangers, reactors, steam drums, and storage tanks can all be made with these plates. They can withstand extremely high temperatures because of their exceptional tensile strength, formability, and resistance to corrosion. SA515 plates are a reliable option for guaranteeing safety and longevity in vital infrastructure, helping to maintain structural integrity in the most demanding applications because of their consistent weldability and durability.
