Based in Hyderabad, India, Daksh Sheets and Plates is a well-known producer and supplier of high-quality metal products that meet a variety of industrial demands. The SA537 Class 1 Boiler Sheet and Plate, designed for high-performance use in boilers and pressure vessels, is one of our specialty products. These plates are perfect for crucial applications in the power, chemical, and energy sectors because of their remarkable strength, resilience to high temperatures, and durability. We make sure that our products fulfill international safety and performance standards by placing a high priority on quality, accuracy, and compliance.
The carbon-manganese-silicon steel alloy SA537 Class 1 is mostly utilized in high-temperature and pressure vessel settings. It is composed of silicon (0.15–0.50%), manganese (0.60–0.90%), carbon (0.20–0.24%), and trace amounts of nickel and chromium to increase strength. Additionally, it contains regulated amounts of sulfur (≤0.035%) and phosphorus (≤0.035%). With a tensile strength of 485–655 MPa, yield strength of 275 MPa, and elongation of 20% over 200 mm, this normalized steel improves mechanical qualities. It is dependable in high-pressure, high-stress situations due to its exceptional toughness and weldability.
Grade : ASME SA 537 CL.1 Boiler and Pressure Vessel Steel Plates
Width : 1000mm-4500mm
Thickness : 5mm-150mm
Length : 3000mm-18000mm
Supply Condition : As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement.
Impact tested : -52° C
Tempering : Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F.
Applications : Used for Boilers and Pressure Vessels Application.
Process of Manufacturing : Hot-Rolled (HR)
| C | Mn | P | S | Si | Cr | Cu | Ni | Mo | |
| ≤ 40 mm | > 40 mm | ||||||||
| 0.24 max | 0.70/1.35 | 1.00/1.60 | 0.035 | 0.035 | 0.15/0.50 | 0.025 | 0.35 | 0.25 | 0.080 |
| Grade | Heat Treatment | Yield (MPa) | Tensile (MPa) | Elongation | Thickness | |
| A50mm | A200mm | |||||
| SA537 Class 1 | Normalized | 345 | 485/620 | 22% | 18% | ≤ 65 |
| 310 | 450/585 | 22% | 18% | > 65 ≤ 100 | ||
| Steel Grade | JIS | Germany |
| ASTM/ASME | G3115 | DIN17155 |
| A537 / SA537 | SPV36 | 19Mn5 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
SA537 Class 1 Boiler Sheet and Plate offer excellent strength, toughness, and resistance to pressure, making them ideal for use in high-temperature and high-pressure applications like boilers and pressure vessels. Their superior weldability allows for easy fabrication, while their resistance to cracking and corrosion enhances reliability in demanding environments. This steel is heat-treated to ensure improved mechanical properties, long-term durability, and performance. With excellent formability and impact resistance, SA537 Class 1 is a trusted choice for power generation, petrochemicals, and manufacturing industries.
SA537 Class 1 Boiler Sheets and Plates are made especially for applications requiring pressure retention in heat exchangers, boilers, and reactors that operate at extremely high temperatures and pressures. Because of their excellent weldability, high tensile strength, and resistance to thermal fatigue, these plates are widely used in the chemical processing, oil and gas, and power generation industries. Pressure vessels, storage tanks, industrial boilers, and manufactured components needing long-term structural stability and dependability are examples of typical applications. In some of the most demanding industrial operations, their ability to endure high-pressure environments guarantees safe and effective performance.
