Located in Delhi, India, Daksh Sheets and Plates is a well-known producer and supplier of high-quality metal products designed for superior industrial performance. We are experts at providing high-performance steel solutions, such as the SA537 Class 2 Boiler Sheet and Plate, which is well-known for its strength, resilience to pressure, and longevity. Our SA537 Class 2 plates are designed to satisfy the rigorous requirements of thermal processing units, petrochemical plants, and power plants. They provide enduring dependability in high-pressure settings. Quality, accuracy, and customer satisfaction are our top priorities at Daksh, and we make sure every product complies with global safety and performance standards.
High-strength, low-alloy steel SA537 Class 2 was created especially for use in boilers and pressure vessels. Carbon (0.17–0.24%), manganese (0.60–1.35%), silicon (0.15–0.50%), and trace elements like copper, sulfur, and phosphorus make up its chemical composition. Heat treatment is applied to the steel to increase its toughness and resistance to stress. It has a tensile strength of 485–620 MPa (70–90 ksi) and a yield strength of 275 MPa (40 ksi). It functions dependably under extreme pressure and temperature conditions and has outstanding notch toughness, weldability, and resistance to heat and corrosion.
Grade : ASME SA 537 CL.2 Boiler and Pressure Vessel Steel Plates
Width : 1000mm-4500mm
Thickness : 5mm-150mm
Length : 3000mm-18000mm
Supply Condition : As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement.
Impact tested : -52° C
Tempering : Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F.
Applications : Used for Boilers and Pressure Vessels Application.
Process of Manufacturing : Hot-Rolled (HR)
| C | Mn | P | S | Si | Cr | Cu | Ni | Mo | |
| ≤ 40 mm | > 40 mm | ||||||||
| 0.24 max | 0.70/1.35 | 1.00/1.60 | 0.035 | 0.035 | 0.15/0.50 | 0.025 | 0.35 | 0.25 | 0.080 |
| Grade | Heat Treatment | Tensile (MPa) | Yield (MPa) | Elongation |
| SA537 Class 2 | Quenched and tempered | 550–690 | 415 | 22% |
| Steel Grade | JIS | Germany |
| ASTM/ASME | G3115 | DIN17155 |
| A537 / SA537 | SPV36 | 19Mn5 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
SA537 Class 2 boiler sheet and plate offer excellent strength and durability, making them ideal for pressure vessels and boiler applications. They are heat-treated to improve their hardness, ensuring resistance to high-pressure environments and elevated temperatures. The material demonstrates excellent weldability, enabling easy fabrication into complex shapes. Its resistance to corrosion and cracking under stress makes it suitable for harsh industrial environments. Additionally, SA537 Class 2 provides good toughness and impact resistance, ensuring long-term reliability in demanding applications such as power plants and chemical processing.
Pressure vessels, boilers, and thermal containers are frequently built using SA537 Class 2 Boiler Sheet and Plate in the petrochemical, chemical processing, and power generation sectors. It is perfect for industrial boilers, heat exchangers, and steam generators due to its resistance to high pressure and heat stress. It is also used in pressurized piping systems, storage tanks, and refineries where strength, resilience to corrosion, and durability are essential. In critical applications that demand dependable performance under high temperatures and fluctuating pressure cycles, SA537 Class 2 is particularly useful.
