Aaron Sheets & Plates is a leading manufacturer and supplier based in Hyderabad , India, specializing in quality stainless steel. With a strong reputation for quality, they offer a wide range of sheets, plates and custom solutions designed to meet the needs of a variety of industries Their stainless steel 17-7 PH angle is known for it is excellent strength, corrosion resistance, excellent fatigue and stress resistant corrosion resistant to cracking , with space, chemical -Ideal for industrial applications exercise.
Stainless Steel 17-7 PH Angle is a precipitation-hardened stainless steel that has trace amounts of silicon, manganese, and nickel in addition to roughly 17% chromium, 7% nickel, and 1% aluminum. This alloy has outstanding corrosion resistance, hardness, and mechanical strength. Following heat treatment, it reaches a yield strength of 758–896 MPa (110–130 ksi) and a tensile strength of 1034–1241 MPa (150–180 ksi). It provides excellent fatigue and creep resistance and maintains dimensional stability in humid or high-stress situations thanks to its hardness of 35 to 45 HRC.
Specifications : ASTM A276, ASTM A479 / ASME SA276, ASME SA479
Angle Size Range : 20 x 20 mm to 100 x 100 mm
Angles Thickness : 3 to 12 mm (depending on size)
Channel Size Range : Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness: 5 to 6 mm (depending on size)
Length : 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| Grade | C | Mn | Ni | Al | Cr | P | Si | S | Fe | |
| 17-7 PH | min. | – | – | 6.50 | 0.75 | 16 | – | – | – | – |
| max. | 0.09 | 1.0 | 7.75 | 1.50 | 18 | 0.040 | 1.0 | 0.030 | Balance | |
| Properties | Metric | Imperial |
| Tensile strength | 1170 MPa | 170000 psi |
| Yield strength | 965 MPa | 140000 psi |
| Modulus of elasticity | 204 GPa | 29600 ksi |
| Poisson’s ratio | 0.27-0.30 | 0.27-0.30 |
| Elongation at break | 6% | 6% |
| Hardness, Rockwell C | 38 | 38 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | AFNOR | BS | GOST | EN |
| SS 17-7 PH | 1.4568 | S17700 | SUS 631 | Z8CNA17.07 | 301S81 | – | X7CrNiAl 17 7 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Based in Hyderabad, India, Aaron Sheets & Plates is a well-known producer and supplier of premium stainless steel goods. Aaron has a solid reputation for quality and provides a large selection of plates, sheets, and specially designed solutions to satisfy a variety of industrial demands. The Stainless Steel 17-7 PH Angle is one of its specialty products; it is renowned for its great strength, resistance to corrosion, and remarkable ability to withstand fatigue and stress corrosion cracking. This material is designed for critical performance and is perfect for the chemical, automotive, and aerospace industries. You can rely on Aaron Sheets & Plates for accuracy, robustness, and reliable product quality.
Stainless steel 17-7 PH (Precipitation Hardened) Angle offers several advantages. Combine excellent strength, superior fatigue resistance and excellent processing power. The material offers excellent corrosion resistance, making it ideal for harsh environments. It is also resistant to high temperatures and can withstand high temperatures without losing its mechanical properties. Stainless steel 17-7 PH Angle is widely used in aerospace, automotive, and construction applications due to its ability to heat treat to varying hardness while maintaining high performance and reliability while also saving cost which is less expensive.
Applications requiring high strength, fatigue resistance, and corrosion performance frequently use 17-7 PH stainless steel angles. They are frequently used in the aerospace industry for precision parts, fasteners, and structural supports. They are perfect for springs, brackets, and high-performance mechanical components in the automotive and defense industries. They are also appropriate for military hardware, valve components, and chemical processing equipment due to their resistance to stress corrosion cracking and high temperatures. In high-load and mission-critical applications where durability, strength, and accuracy are crucial, 17-7 PH angles provide dependable performance.
