Based in Hyderabad, India, Daksh Sheets and Plates is a top producer and supplier of high-end stainless steel goods, such as SS 17-7 PH Sheets and Plates. These materials are well-known for their exceptional strength, resilience to corrosion, and longevity, making them perfect for demanding uses in the industrial, chemical, and aerospace industries. Daksh guarantees that every product satisfies exacting performance standards by emphasizing customized solutions, accurate manufacturing, and on-time delivery. Our 17-7 PH stainless steel products are designed to function well in corrosive and high-stress situations, making us a dependable partner for businesses in India and abroad.
The main constituents of SS 17-7 PH (UNS S17700), a precipitation-hardened stainless steel alloy, are 17% chromium, 7% nickel, and trace amounts of carbon, silicon, and phosphorus. Other minor elements include 1% aluminum and 1% manganese. In its hardened state, the alloy has a yield strength of 1,100 MPa (160 ksi) and a tensile strength of up to 1,300 MPa (190 ksi). It is suitable for demanding, high-performance applications due to its exceptional fatigue resistance, stress-corrosion resistance, and Rockwell hardness of C45, which allows it to tolerate temperatures up to 480°C (900°F) after aging.
| Specifications : | ASTM A693 / ASME SA693 |
| Standard : | ASTM, ASME and API |
| Thickness : | 4.0mm – 100mm |
| Shims Thickness : | Range from .01″ to .0125″ |
| Specialize : | Shim Sheet, Perforated Sheet, B. Q. Profile. |
| Form : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade : | SS 17-7 PH, (UNS S17700) |
| Grade | C | Mn | Ni | Al | Cr | P | Si | S | Fe | |
| 17-7 PH | min. | – | – | 6.50 | 0.75 | 16 | – | – | – | – |
| max. | 0.09 | 1.0 | 7.75 | 1.50 | 18 | 0.040 | 1.0 | 0.030 | Balance | |
| Properties | Metric | Imperial |
| Tensile strength | 1170 MPa | 170000 psi |
| Yield strength | 965 MPa | 140000 psi |
| Modulus of elasticity | 204 GPa | 29600 ksi |
| Poisson’s ratio | 0.27-0.30 | 0.27-0.30 |
| Elongation at break | 6% | 6% |
| Hardness, Rockwell C | 38 | 38 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
SS DIN 1.4568 Sheets and Plates offer numerous advantages, including exceptional strength, high fatigue resistance, and excellent stress-corrosion cracking resistance. This alloy maintains good mechanical properties at elevated temperatures, making it ideal for aerospace and industrial applications. It also provides excellent formability and can be easily hardened through heat treatment. The material exhibits superior weldability, ensuring reliable performance in critical environments. Its corrosion resistance, combined with high durability, makes it a preferred choice for manufacturing components that require both strength and resistance to harsh conditions.
| Properties | Metric | Imperial |
| Density | 7.80 g/cm3 | 0.282 lb/in3 |
Yes, we offer custom sizes for Stainless Steel 17-7 PH Sheet and Plates to meet specific project needs. Our team at Daksh Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@dakshsheetsandplates.co.in
| STANDARD | WERKSTOFF NR. | UNS | JIS | AFNOR | BS | GOST | EN |
| SS 17-7 PH | 1.4568 | S17700 | SUS 631 | Z8CNA17.07 | 301S81 | – | X7CrNiAl 17 7 |
| Material | Size | Thickness |
|---|---|---|
| PLATES / SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
SS 17-7 PH Industries that require outstanding strength, resistance to corrosion, and dimensional stability frequently use sheets and plates. Because of their exceptional strength-to-weight ratio, they are utilized in the aerospace industry in landing gear, fasteners, and aircraft structures. Additionally, the alloy is used in medical devices, springs, valves, and chemical processing equipment where fatigue resistance and durability are essential. It is also used in precision engineering, food processing equipment, and automotive components that are exposed to high temperatures and mechanical strain. It is an excellent option for high-performance industrial applications due to its versatility.
