Premium-grade stainless steel 201 angles are available from Daksh Sheets and Plates, a reputable manufacturer and supplier with headquarters in Delhi, India, for a range of structural and industrial uses. Our SS 201 angles are made with premium raw materials and cutting-edge manufacturing techniques, and they are designed for strength, affordability, and resistance to corrosion. These angles are perfect for fabrication, construction, and general structural applications, particularly when durability and cost-effectiveness are important factors. Daksh caters to industries in India and overseas markets with its accurate dimensions, high-quality surface finish, and adjustable sizes. On-time delivery, reliable quality, and total client satisfaction are our top priorities.
Stainless Steel 201 is an austenitic alloy based on manganese that has a carbon content of up to 0.15% and contains 16–18% chromium, 3.5–5.5% nickel, and 5.5–7.5% manganese. Because of this composition, SS 201 angles have good toughness, moderate corrosion resistance, and high strength. It maintains respectable formability and weldability while providing a tensile strength of 520–750 MPa. It is more difficult and expensive than SS 304, but it offers less resistance to corrosion. The alloy is appropriate for cold working and fabrication and works well in indoor and mildly corrosive environments.
| Specifications | ASTM A 276/A 276M,A 484/A 484M,A 564/A 564M,A 582/A582M,A 638 /A 638M,A705/A705M |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| SS 201 Angle | 5mm to 9mm |
| Thickness | 3.0mm – 120mm |
| Length | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
| Grade | C | Mn | Si | P | S | Cr | Ni | N |
| SS 201 | 0.15 max | 5.5 – 7.5 | 100 max | 0.06 max | 0.03 max | 16.00-18.00 | 0.3 – 0.5 | – |
| Temper | Tensile Strength | Yield Strength | Elongation | Rockwell | ||
|---|---|---|---|---|---|---|
| KSi | MPa | KSi | MPa | in 2 inches % | ||
| 1/2 Hard | 150 | -1034 | 110 | -758 | 10 | C-32 |
| 1/4 Hard | 125 | -862 | 75 | -517 | 20 | C-25 |
| 3/4 Hard | 175 | -1207 | 135 | -931 | 7 | C-37 |
| Annealed | 95 | -655 | 45 | -310 | 40 | B-90 max. |
| Full Hard | 185 | -1276 | 140 | -965 | 5 | C-41 |
| STANDARD | UNS | WERKSTOFF NR. |
| SS 201 | S20100 | 1.4372 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Width (mm) | Thickness (mm) | Width (Inches) | Thickness (Inches) |
|---|---|---|---|
| 20 x 20 | 3 to 5 | 3/4″ | 1/8 to 1/4 |
| 25 x 25 | 3 to 5 | 1″ | 1/8 to 1/4 |
| 30 x 30 | 3 to 5 | 1.1/8 | 1/8 to 1/4 |
| 32 x 32 | 3 to 6 | 1.1/4 | 1/8 to 1/4 |
| 35 x 35 | 3 to 6 | 1.3/8 | 1/8 to 1/4 |
| 38 x 38 | 3 to 6 | 1.1/2 | 1/8 to 1/4 |
| 40 x 40 | 3 to 6 | 1.5/8 | 1/8 to 1/4 |
| 45 x 45 | 3 to 6 | 1.3/4 | 1/8 to 1/4 |
| 50 x 50 | 3 to 6 | 2″ | 1/8 to 1/4 |
| 60 x 60 | 5 to 6 | 2.3/8 | 3/16 to 1/4 |
| 65 x 65 | 5 to 6 | 2.1/2 | 3/16 to 1/4 |
| 70 x 70 | 5 to 6 | 2.3/4 | 3/16 to 1/4 |
| 75 x 75 | 5 to 6 | 3″ | 3/16 to 1/4 |
In structural, architectural, and fabrication applications where high strength and cost effectiveness are necessary, stainless steel 201 angles are frequently utilised. Support frames, building structures, window and door frames, kitchenware and furnishings are among the frequently used applications. They are also appropriate for lightweight structural frameworks, storage systems, and transportation. For indoor or outdoor settings with minimal exposure to corrosive elements, SS 201 angles are perfect. They are a common option for general-purpose construction and fabrication tasks due to their good machinability and weldability, which provide durability, aesthetic appeal, and a cost-effective substitute for higher-nickel stainless steels.
