Based in Delhi, India, Daksh Sheets and Plates is a top producer and supplier of stainless steel 304 angles. We are renowned for providing premium stainless steel products that adhere to international standards for robustness, longevity, and resistance to corrosion. With the use of top-notch raw materials and cutting-edge manufacturing processes, our SS 304 angles are produced with exact measurements and superior surface finish. These angles come in a range of thicknesses and sizes and are perfect for both decorative and structural applications. Daksh provides specialised solutions, prompt delivery, and trustworthy customer support to a broad range of industries in India and overseas.
Stainless steel 304 is an austenitic alloy with low carbon (maximum 0.08%) for better weldability and 18–20% chromium and 8–10.5% nickel. In a variety of chemical and atmospheric conditions, it provides exceptional corrosion resistance. Even at cryogenic temperatures, SS 304 angles exhibit good ductility, formability, and toughness, with a tensile strength ranging from 515 to 750 MPa. Under typical operating conditions, the alloy retains its high strength and structural integrity, making it a dependable and adaptable option for indoor and outdoor applications in architectural and industrial settings.
| Standard | ASME, ASTM, EN, BS, GB, DIN, JIS, etc |
| Size | 3/4″ THRU 8″ |
| Thickness | 1/8″ thru 5/8″ |
| Type | Stuctural Steel Angle, Bars, Equal, Unequal, L, T, Hot Rolled |
| Grades | 304/304L/304H/310S/316/316L/316H/316TI/317/317L/321/321H/904L |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
|---|---|---|---|---|---|---|---|---|
| Stainless 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| SS 304 | 1.4301 | S30400 | SUS 304 | 304S31 | 08Х18Н10 | Z7CN18‐09 | X5CrNi18-10 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Size in Inches | Est. Weight per Ft. Lbs. | Est. Weight per 20′ Bar |
|---|---|---|
| 3/4 x 3/4 x 1/8 | 0.59 | 11.80 |
| 1 x 1 x 1/8 | 0.80 | 16.00 |
| 1 x 1 x 3/16 | 1.16 | 23.20 |
| 1 x 1 x 1/4 | 1.49 | 29.80 |
| 1-1/4 x 1-1/4 x 1/8 | 1.01 | 20.20 |
| 1-1/4 x 1-1/4 x 3/16 | 1.48 | 29.60 |
| 1-1/4 x 1-1/4 x 1/4 | 1.92 | 38.40 |
| 1-1/2 x 1-1/2 x 1/8 | 1.23 | 24.60 |
| 1-1/2 x 1-1/2 x 3/16 | 1.80 | 36.00 |
| 1-1/2 x 1-1/2 x 1/4 | 2.34 | 46.80 |
| 2 x 2 x 1/8 | 1.65 | 33.00 |
| 2 x 2 x 3/16 | 2.44 | 48.80 |
| 2 x 2 x 1/4 | 3.19 | 63.80 |
| 2 x 2 x 3/8 | 4.70 | 94.00 |
| 2-1/2 x 2-1/2 x 3/16 | 3.07 | 61.40 |
| 2-1/2 x 2-1/2 x 1/4 | 4.10 | 82.00 |
| 3 x 3 x 1/4 | 4.90 | 98.00 |
| 4 x 4 x 1/4 | 6.60 | 132.00 |
| 4 x 4 x 3/8 | 9.80 | 196.00 |
Because of their exceptional mechanical strength and resistance to corrosion, stainless steel 304 angles are frequently used in industrial, architectural, and construction settings. Structural frameworks, support brackets, shelving systems, walkways, and reinforcements are examples of common applications. These angles are preferred in the chemical, pharmaceutical, and food processing industries due to their oxidation resistance and hygienic qualities. They are also used in industries where strength and durability are crucial, such as transportation, automotive, marine, and fabrication. Because SS 304 angles are simple to form and weld, they can be used in both indoor and outdoor settings for both standard and custom designs.
