Based in Delhi, India, Daksh Sheets and Plates is a reputable producer and supplier of stainless steel 304H angles. Our speciality is manufacturing high-end stainless steel products that satisfy the requirements of structural and high-temperature applications. Our SS 304H angles are manufactured with superior strength, dimensional accuracy, and corrosion resistance by employing advanced manufacturing techniques and premium raw materials. These angles provide improved performance in heat exchangers, boilers, and pressure vessels and are particularly well-suited for high temperature settings. Daksh is dedicated to providing customers in India and international markets with timely, high-quality, and customised service.
A high-carbon variant of stainless steel 304, 304H has a carbon content of 0.04–0.10%, 18–20% chromium, and 8–11% nickel. Better creep resistance and higher high-temperature strength are provided by the higher carbon content. Even at higher temperatures, SS 304H angles exhibit exceptional toughness and a tensile strength of 515–740 MPa. In oxidising environments, this alloy also retains good corrosion resistance and weldability. When annealed, it is non-magnetic and works consistently in applications requiring both mechanical strength and thermal stability under pressure.
| Specifications | ASTM A/ASME SA213/A249/A269/A312/A358 CL. I to V ASTM A789/A790 |
|---|---|
| Dimensions | ASTM, ASME and API |
| 304 Pipes & Tubes | 1/2″ NB – 16″ NB |
| ERW 304 Pipes & Tubes | 1/2″ NB – 24″ NB |
| EFW 304 Pipes & Tubes | 6″ NB – 100″ NB |
| Size | 1/8″NB TO 30″NB IN |
| Specialized in | Large Diameter Size |
| Schedule | SCH5, SCH10, SCH20, SCH30, SCH40, Std, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Type | Seamless / ERW / Welded / Fabricated / LSAW Pipes |
| Form | Round, Square, Rectangular, Hydraulic Etc |
| Length | Single Random, Double Random & Cut Lengtd. |
| End | Plain End, Beveled End, Treaded |
| C | MN | SI | P | S | CR | NI | N | |
|---|---|---|---|---|---|---|---|---|
| 304 | 0.07max | 2.0max | 0.75max | 0.045max | 0.03max | min: 18.0 max: 20.0 | min: 8.0 max: 10.5 | — |
| 304H | min: 18.0 max:20.0 | min: 8.0 max: 10.5 | min: 0.04 max:0.10 | 0.75 max | 2.0 max | 0.045 max | 0.03 max | 0.10 max |
| Grade | Tensile Strength ksi (min) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Brinell) MAX | Hardness (Rockwell B) MAX |
|---|---|---|---|---|---|
| 304 | 75 | 30 | 40 | 201 | 92 |
| 304H | 75 | 30 | 40 | 201 | 92 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 304H | 1.4948 | S30409 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Daksh Sheets and Plates based in Hyderabad , India, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
| SS 304 | ||||||
|---|---|---|---|---|---|---|
| Density lbm/in3 | Thermal Conductivity (BTU/h ft. °F) | Electrical Resistivity (in x 10-6) | Modulus of Elasticity (psi x 106 | Coefficient of Thermal Expansion (in/in)/ °F x 10-6 | Specific Heat (BTU/lb/ °F) | Melting Range (°F) |
| at 68°F: 0.285 | 9.4 at 212°F | 28.3 at 68°F | 28 | 9.4 at 32 – 212°F | 0.1200 at 68°F to 212°F | 2500 to 2590 |
| 12.4 at 932 °F | 39.4 at 752°F | 10.2 at 32 – 1000°F | ||||
| 49.6 at 1652 °F | 10.4 at 32 – 1500°F | |||||
| SS 304H | ||||||
| Denstiy lbm/in3 | Coefficient of Thermal Expansion (min/in)-°F | Thermal Conductivity BTU/hr-ft-°F | Specific Heat BTU/lbm -°F | Modules of Elasticity (annealed)2-psi | ||
| at 68 °F | at 68 – 212°F | at 68 – 1600°F | at 212°F | at 932°F | at 32 – 212°F | in tension (E) |
| 0.285 | 9.2 | 11.0 | 9.4 | 12.4 | 0.12 | 29 x 106 |
In industries where resistance to high temperatures and structural integrity are essential, stainless steel 304H angles are frequently utilised. Heat exchangers, boilers, superheaters, pressure vessels, and piping systems in refineries, petrochemical plants, and power plants are examples of common applications. These angles are also utilised in support structures and construction frameworks that are subjected to high temperatures. They are appropriate for settings that demand greater mechanical strength at high temperatures due to their increased carbon content. Furthermore, SS 304H angles are employed in the pharmaceutical and food processing sectors, where long-term performance under heat stress requires materials that are corrosion-resistant, strong, and clean.
