In Delhi, India, Daksh Sheets and Plates is a reputable manufacturer and supplier of stainless steel 309H sheets and plates. They provide high-performance materials made to withstand the demanding conditions of corrosive and high-temperature environments. Superior quality raw materials and cutting-edge production methods are used in the manufacturing of our SS 309H sheets and plates to guarantee exceptional strength, durability, and resistance to heat stress. Daksh provides dependable and reasonably priced stainless steel solutions to a range of industries, including power generation, petrochemical, furnace manufacturing, and heat treatment applications in India and overseas markets. The company is dedicated to quality, timely delivery, and customer satisfaction.
About 22–24% chromium and 12–15% nickel make up stainless steel 309H sheets and plates. A higher carbon content (0.04–0.10%) improves creep resistance and high-temperature strength. Up to 1000°C, this austenitic stainless steel provides exceptional resistance to oxidation. Its elongation is approximately 40%, its yield strength is 205 MPa, and its tensile strength is approximately 550 MPa. Because of its increased strength and resistance to corrosion under high service conditions, SS 309H is appropriate for equipment that is subjected to pressure and high temperatures while maintaining structural integrity in thermal cycling environments.
| Specifications | ASTM A240 / ASME SA240 |
| Size | 1/4″ to 4″ |
| Range | 5mm To 150mm |
| Thickness | 4mm-100mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mn | Si | P | S | Cr | Ni | Fe | |
| SS 309 | 0.20 | 2 | 1 | 0.045 | 0.030 | 23 | 14 | 60 | |
| SS 309H | 0.04-0.10 | 2.0 | 0.75 | 0.045 | 0.03 | 22.0-24.0 | 15.0 | 58.0-63.0 | |
| Grade | Tensile Strengtd ksi (min) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Brinell) max |
| 309/S | 75 | 30 | 40 | 95 |
| 309/H | 40 | 30 | 40 | 217 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 309H | 1.4833 | S30909 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Applications requiring constant exposure to high temperatures and harsh corrosive conditions frequently use stainless steel 309H sheets and plates. Heat exchangers, boilers, kilns, furnace parts, and other heat-resistant structural components are among the common applications. These plates are used in high-temperature processing devices like reactors, combustion chambers, and radiant tubes in power plants and the petrochemical sector. Incinerators, waste treatment systems, and thermal processing units also use SS 309H. Equipment subjected to high temperatures and thermal cycling benefits greatly from its resilience to oxidation and durability, which guarantees dependability and longevity under the most demanding industrial circumstances.
