Based in Hyderabad, India, Daksh Sheets and Plates is a reputable producer and supplier of premium metal goods. Our specialty is stainless steel 310 sheets and plates, which provide strong, heat-resistant solutions for demanding commercial and industrial applications. Our products meet strict international standards and are renowned for their exceptional strength, dependability, and resistance to corrosion at high temperatures. Power, petrochemical, and thermal processing are just a few of the industries that Daksh Sheets and Plates serves with a strong dedication to precision engineering, on-time delivery, and customer satisfaction. Join forces with us for unrivaled technical excellence and consistent quality.
Chromium (24–26%) and nickel (19–22%) make up the majority of stainless steel 310 sheets and plates, with iron, carbon, manganese, and silicon added in balance. At high temperatures up to 1150°C, this chemical composition provides exceptional resistance to oxidation and corrosion. Mechanically, SS 310 has an elongation of about 40%, a yield strength of 205 MPa, and a tensile strength of roughly 515 MPa. The alloy is a popular option for high-temperature service in demanding environments due to its exceptional formability, weldability, and thermal stability.
| Specifications | ASTM A240 / ASME SA240 |
|---|---|
| Width | 1000mm / 1219mm /1250mm / 1500mm / 2000mm |
| Length | 2000 mm / 2440 mm / 2500 mm / 3000 mm / 6000 mm |
| Thickness | 0.1mm to 12 mm Thk |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 310 | 0.015 max | 2.0 max | 0.15 max | 0.020 max | 0.015 max | 24.00 – 26.00 | 0.10 max | 19.00 – 21.00 | 54.7 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1402 °C (2555 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 310 | 1.4841 | S31000 | SUS 310 | 310S24 | 20Ch25N20S2 | – | X15CrNi25-20 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
| 2000MM X 1000MM X 3MM | 2000MM X 1000MM X 6MM |
| 2500MM X 1250MM X 4MM | 2500MM X 1250MM X 8MM |
| 3000MM X 1500MM X 3MM | 3000MM X 1500MM X 6MM |
| 3000MM X 1500MM X 4MM | 3000MM X 1500MM X 8MM |
| 2000MM X 1000MM X 5MM | 2500MM X 1250MM X 10MM |
| 2500MM X 1250MM X 3MM | 2500MM X 1250MM X 6MM |
| 4000MM X 2000MM X 3MM | 4000MM X 2000MM X 6MM |
| 2500MM X 1250MM X 5MM | 3000MM X 1500MM X 10MM |
| 2000MM X 1000MM X 4MM | 2000MM X 1000MM X 8MM |
| 4000MM X 2000MM X 4MM | 2000MM X 2000MM X 10MM |
| 3000MM X 1500MM X 5MM |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 310 sheet and plate offer exceptional mechanical advantages. Their high chromium and nickel content ensures excellent resistance to oxidation, corrosion and scaling at temperatures up to 1150°C. These sheets and plates are durable, durable, and provide mechanical stability under thermal cycling. They exhibit excellent weldability and formability, making them easy to manufacture in complex structures. Additionally, they operate reliably in turbulent environments, including chemical processing plants, heat exchangers and furnaces. Their low maintenance and long life make them cost-effective and reliable for complex applications.
Applications involving high temperatures and corrosive conditions are best suited for stainless steel 310 sheets and plates. They are ideal for furnace parts, heat exchangers, kilns, and burner tips due to their exceptional resistance to oxidation, scaling, and heat fatigue. They handle acids, alkalis, and process heat in the chemical and petrochemical industries. Because of its exceptional performance across a broad temperature range, SS 310 is also favored in power plants, refineries, and cryogenic systems. These sheets and plates are also utilized in food processing, medical equipment, and kitchen equipment where durability and cleanliness are essential.
