Based in Delhi, India, Daksh Sheets and Plates is a reputable manufacturer and supplier of premium stainless steel goods, such as Stainless Steel 316 Circles. Superior quality raw materials and cutting-edge technology are used in the production of these circles to guarantee their longevity, resistance to corrosion, and dimensional accuracy. SS 316 circles are suitable for both decorative and industrial applications. They satisfy international standards and are used in industries like food processing, pharmaceuticals, chemical processing, and marine environments. Customer satisfaction, prompt delivery, and dependable stainless steel solutions that satisfy the changing demands of both domestic and international markets are all priorities for Daksh Sheets and Plates.
The composition of stainless steel 316 circles, which includes 16–18% chromium, 10–14% nickel, and 2–3% molybdenum, improves corrosion resistance, particularly in environments with high chloride levels. It also contains trace amounts of silicon, manganese, and carbon (≤0.08%). Mechanically, SS 316 circles have an elongation of about 40%, a yield strength of roughly 205 MPa, and a tensile strength of 515–700 MPa. It has exceptional resistance to pitting and crevice corrosion thanks to the addition of molybdenum. These circles are perfect for demanding applications needing high performance and long service life because of their strength, weldability, and formability.
| Standard | ASTM A240, ASME SA240 |
| Dimensions | ASTM, ASME and API |
| Standard | JIS, AISI, ASTM, GB, DIN, EN, etc. |
| Thickness | 1 Mm To 100 mm. |
| Diameter | Upto 2000 Mm. |
| Circle Diameter | 3″ DIA up to 38″ DIA 1500 lbs max. |
| Circles Form | Cold Rolled, Small Flat, Industrial, Proof Machined, Perforated, Forged Steel, Cnc Finish, Polished Unique, Hot Rolled Circle.. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 | 67.845 min |
| Grades | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 316 | 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | – | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
| Size | 18 G. | 19 G. | 20 G. | 22 G. | 24 G. | 26 G. |
| .4.5 | .0-107 | 0-085 | 0-080 | 0-062 | 0.049 | 0-040 |
| 5 | 0-120 | 0-095 | 0-090 | 0-070 | 0-055 | 0-045 |
| 5.5 | 0-146 | 0-119 | 0-109 | 0-085 | 0-066 | 0-054 |
| 6 | 0-172 | 0-136 | 0-130 | 0-100 | 0-079 | 0-064 |
| 6.5 | 0-200 | 0-153 | 0-150 | 0-128 | 0-093 | 0-074 |
| 7 | 0-235 | 0-190 | 0-176 | 0-136 | 0-107 | 0-088 |
| 7.5 | 0.270 | 0.212 | 0.201 | 0-157 | 0-123 | 0-100 |
| 8 | 0-307 | 0-240 | 0-230 | 0-180 | 0-140 | 0-115 |
| 8.5 | 0-347 | 0-270 | 0-262 | 0-202 | 0-156 | 0-130 |
| 9 | 0-388 | 0-330 | 0-301 | 0-230 | 0-178 | 0-145 |
| 9.5 | 0-472 | 0-342 | 0-324 | 0-252 | 0-198 | 0-162 |
| 10 | 0-480 | 0-380 | 0-360 | 0-280 | 0-220 | 0-180 |
| 11 | 0-580 | 0-450 | 0-435 | 0-338 | 0-266 | 0-218 |
| 12 | 0-690 | 0-540 | 0-518 | 0-403 | 0-318 | 0-253 |
| 13 | 0-811 | 0-640 | 0-508 | 0-608 | 0-371 | 0-304 |
| 14 | 0-940 | 0-750 | 0-708 | 0-558 | 0-430 | 0-352 |
| 15 | 1-080 | 0-860 | 0-808 | 0-650 | 0-495 | 0-405 |
| 16 | 1-228 | 0-960 | 0-921 | 0-736 | 0-563 | 0-460 |
| 17 | 1-382 | 1-080 | 0-940 | 0-809 | 0-635 | 0-560 |
| 18 | 1-595 | 1-200 | 1-116 | 0-907 | 0-712 | 0-683 |
| 19 | 1-732 | 1-350 | 1-300 | 1-010 | 0-794 | 0-750 |
| 20 | 1-920 | 1-400 | 1-340 | 1-120 | 0-880 | 0-785 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Industries needing high strength and resistance to corrosion frequently use stainless steel 316 circles. Because of their resistance to acidic and chloride environments, they are perfect for heat exchangers, chemical processing equipment, marine hardware, and pharmaceutical machinery. These circles are utilised in kitchen tools, processing machinery, and storage tanks in the food and beverage sector. Additionally, SS 316 circles are used in paper pulp machinery, medical equipment, and architectural structures. Both structural and aesthetic applications where strength, cleanliness, and resistance to corrosion are crucial can benefit from their longevity, ease of fabrication, and superior hygienic qualities.
