Daksh Sheets and Plates is pleased to offer premium 316L stainless steel sheets and plates that are made to satisfy the exacting requirements of numerous industrial sectors. We are a reputable brand for premium stainless steel products with exceptional durability and corrosion resistance, and we are based in Delhi, India. The low carbon content and superior resistance to chloride environments of our SS 316L materials are well known. They are perfect for use in chemical, pharmaceutical, and marine applications. Daksh guarantees precisely engineered products that satisfy international standards and are appropriate for demanding applications where weldability and corrosion resistance are essential.
With a maximum of 0.03% carbon, 10–14% nickel, 2–3% molybdenum, and roughly 16–18% chromium, stainless steel 316L is extremely resistant to pitting and crevice corrosion. Sensitisation during welding is reduced by the low carbon content. Even at below-freezing temperatures, it provides outstanding ductility and toughness along with a tensile strength of 485 MPa and a yield strength of 170 MPa. When annealed, SS 316L is non-magnetic and has excellent weldability. It is a popular option in harsh environments because of its strength and resistance to corrosion.
| Specifications | : | ASTM A240 / ASME SA240 |
| Thickness | : | 4mm-100mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316L | 0.035 max | 2 max | 1.00 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.89 min |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 316L | 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
| Surface Finish | Definition | Application |
|---|---|---|
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
| BA | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
| NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Chemical processing facilities, pharmaceutical manufacturing facilities, and marine environments all make extensive use of stainless steel 316L sheets and plates. It is perfect for pharmaceutical equipment, surgical instruments, and coastal structural applications due to its low carbon content and high corrosion resistance. Because of its exceptional performance in chloride-rich environments, the alloy can be used in food processing equipment, offshore oil platforms, and desalination plants. Additionally, SS 316L is frequently utilised in pulp and paper and architectural applications where cleanliness, corrosion resistance, and ease of cleaning are essential. It is a material of choice for intricate assemblies due to its high weldability.
