In Delhi, India, Daksh Sheets and Plates is a leading producer and supplier of 316Ti stainless steel sheets and plates. SS 316Ti is an improved titanium-stabilized version of 316 that is ideal for high-temperature and corrosive environments because of its superior corrosion and heat resistance. Customised sheet and plate dimensions are available from Daksh, guaranteeing top performance for a variety of industrial applications. Customers in industries like power generation, pharmaceuticals, food processing, and marine engineering choose us because of our emphasis on quality control, timely service, and affordable prices.
With its composition of 16–18% Chromium, 10–14% Nickel, 2–3% Molybdenum, and 0.5% Titanium, SS 316Ti stabilises the structure against intergranular corrosion. During welding procedures and at high temperatures, this alloy retains its mechanical integrity. It offers an elongation of roughly 40%, a yield strength of 205 MPa, and a tensile strength of 515–620 MPa. Titanium is added to increase heat resistance and decrease carbide precipitation when exposed to heat. Because of its exceptional resistance to high-temperature oxidation, stress corrosion, and pitting, SS 316Ti is a dependable material for intricate industrial fabrication.
| Specifications | : | ASTM A240 / ASME SA240 |
| Thickness | : | 4mm-100mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316Ti | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.395 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316Ti | 1.4571 | S31635 | SUS 316Ti | 320S31 | 08Ch17N13M2T | Z6CNDT17‐123 | X6CrNiMoTi17-12-2 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
| Surface Finish | Definition | Application |
|---|---|---|
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
| BA | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
| NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Heat exchangers, exhaust systems, and high-temperature pressure vessels all frequently use stainless steel 316Ti sheets and plates. They are perfect for applications requiring extended exposure to high temperatures or welding operations because of the titanium stabilisation. They are frequently used for tanks, pipelines, and reaction vessels in the petrochemical and chemical industries. They are appropriate for food processing equipment and marine structures due to their resistance to corrosion. Furthermore, SS 316Ti finds use in flue gas systems, pharmaceutical manufacturing equipment, and architectural applications where long-term durability, temperature stability, and hygiene are crucial performance criteria. Additionally, refinery and aerospace components favour it.
