In Delhi, India, Daksh Sheets and Plates is a top producer and supplier of stainless steel 317L foils, providing high-end goods designed to satisfy the demands of sectors needing remarkable accuracy and resistance to corrosion. Daksh produces 317L foils that are renowned for their exceptional surface finish, high performance, and durability through sophisticated production methods and stringent quality control. These foils are perfect for high-temperature applications and harsh chemical environments. Supported by technical know-how and customer-focused service, Daksh provides clients in a variety of industries with on-time delivery and tailored solutions that meet industry and global quality standards.
An austenitic chromium-nickel-molybdenum alloy, stainless steel 317L foil has a low carbon content (maximum 0.03%), roughly 18–20% chromium, 11–15% nickel, and 3–4% molybdenum. In environments that are acidic and chloride-rich, this composition improves resistance to pitting and chemical attack. The alloy has good ductility and formability, a yield strength of 205 MPa, and a tensile strength of about 515 MPa. It provides outstanding weldability and corrosion resistance, particularly in settings where intergranular corrosion is an issue, and it retains mechanical integrity at high temperatures.
| SPECIFICATION: | ASTM A240 / SA240 |
| STANDARD | JIS, AISI, ASTM, DIN, GB, EN, ETC |
| SURFACE | 2B, CR, HR, 2D, NO.4, NO.8, MIRROR, BA, NO.1, CHEQUERED, HAIRLINE, BRUSH, ETCHING, ETC. |
| WIDTH | 1000MM, 1219MM, 1250 MM, 1500MM, 2000MM AND Even as per Customers Requirements |
| LENGTH | 2000MM, 2500MM, 3000 MM, 5000MM, 6000MM AND Even as per Customers Requirements |
| THICKNESS | 0.05MM TO 150 MM |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 317L | 0.035 max | 2 max | 1 max | 0.040 max | 0.03 max | 18 – 20 | 3 – 4 | 11 – 15 | – |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1454 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| GRADE 317L | ||||
|---|---|---|---|---|
| ASTM | DIN | UNS | JIS | GB |
| 317L | 1.4438 | S31703 | SUS317L | X2CrNiMo19-14-4 |
Industries that require precision and high corrosion resistance make extensive use of stainless steel 317L foils. Because of their resistance to harsh acids and chlorides, they are used in processing equipment, heat exchangers, and storage tanks in the chemical and petrochemical industries. 317L foils guarantee clean, hygienic surfaces in the food processing and pharmaceutical industries. Additionally, they are employed in pulp and paper production, flue gas cleaning systems, and maritime applications. They are perfect for gasket fabrication, insulation wrapping, and other custom industrial components that need to be formable and resistant to chemicals because of their strength and flexibility.
