Leading the way in cutting-edge stainless steel production in Delhi, India, Daksh Sheets and Plates provides high-grade Stainless Steel 347 Sheets and Plates for vital industrial uses. We are dedicated to providing high-performance materials with exceptional thermal stability and corrosion resistance as a top supplier. Our SS 347 plates and sheets are designed to function well in harsh environments, especially welded and high-temperature settings. Focussing on innovation, dependability, and client satisfaction, Daksh guarantees expertly designed products supported by prompt service, technical assistance, and a solid reputation for satisfying the needs of sectors like marine, chemical, and aerospace.
The main constituents of Stainless Steel 347, an austenitic stainless steel alloy stabilised by niobium, are 17–19% chromium and 9–13% nickel. Columbium and tantalum are added to stop intergranular corrosion. This grade resists carbide precipitation during welding and maintains strength at high temperatures. It has an elongation of 40%, a yield strength of 205 MPa, and a tensile strength of about 515 MPa. Additionally, SS 347 has outstanding stress-rupture and oxidation resistance, which makes it perfect for applications requiring extended heat exposure or frequent thermal cycling. Because it is non-magnetic, the alloy can be used in structural and pressure applications.
| Specifications | : | ASTM A240 / ASME SA240 |
| Thickness | : | 4mm-100mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mn | Si | P | S | Cr | Cb | Ni | Fe |
| SS 347 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 20.00 | 10xC – 1.10 | 9.00 – 13.00 | 62.74 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1454 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 347 | 1.4550 | S34700 | SUS 347 | – | 08Ch18N12B | – | X6CrNiNb18-10 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
| Surface Finish | Definition | Application |
|---|---|---|
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
| BA | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
| NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 347 sheets and plates are widely used in applications requiring high temperatures and resistance to corrosion. It is commonly used in the chemical industry, power generation, and aerospace. Intergranular corrosion resistance makes them ideal for welded components in areas such as petrochemical plants and refineries. In addition, stainless steel 347 is used in heat exchangers, furnace components, combustion chambers and high-temperature tanks. Its excellent mechanical characteristics and durability make it desirable for critical applications where reliability and performance are important.
