Based in Delhi, India, Daksh Sheets and Plates is a reputable producer and supplier of high-performance stainless steel 348H sheets and plates. Daksh offers dependable solutions for demanding industrial environments with a focus on stainless steel products that are resistant to heat and corrosion. Stabilised austenitic stainless steel 348H is perfect for applications requiring high pressure and temperature. Daksh guarantees that every product satisfies international standards through the use of cutting-edge technology and strict quality controls during manufacturing. Daksh provides services to the chemical processing, power generation, aerospace, and thermal engineering sectors in India with an emphasis on longevity, dimensional accuracy, and customer satisfaction.
The main constituents of stainless steel 348H sheets and plates are 17–20% chromium, 9–13% nickel, and a higher carbon content (0.04–0.10%) for high-temperature strength. Tantalum and columbium (niobium) stabilise them, preventing carbide precipitation during thermal exposure or welding. Excellent resistance to oxidation and intergranular corrosion is provided by the material. Tensile strength ranges from 515 to 690 MPa, and yield strength is roughly 205 MPa. Additionally, in environments with persistently high temperatures and harsh chemical exposure, these sheets and plates maintain their mechanical integrity and offer superior creep resistance.
| Specifications | ASTM A240 / ASME SA240 |
|---|---|
| Width | 1000mm / 1219mm /1250mm / 1500mm / 2000mm |
| Length | 2000 mm / 2440 mm / 2500 mm / 3000 mm / 6000 mm |
| Thickness | 0.1mm to 12 mm Thk |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | Mn | P | C | S | Cr | Si | Ni | Fe | Co |
| SS 348H | 2.00 | 0.045 | 0.04-0.10 | 0.030 | 17.00-19.00 | 0.75 | 9.00-13.00 | – | – |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1402 °C (2555 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40 % |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 348H | 1.4546 | S34809 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 348H sheets and plates are perfect for industries like power generation, petrochemicals, refineries, and aerospace because they are made for high-temperature and high-pressure applications. Boiler tubes, exhaust systems, pressure vessels, heat exchangers, and superheaters are examples of common applications. They are ideal for thermal processing environments because of their resistance to intergranular corrosion and ability to retain mechanical strength under cyclic heating and cooling conditions. Additionally, 348H is a good fit for parts of nuclear reactors and chemical processing machinery where thermal stability and corrosion resistance are crucial. The alloy is a popular option for critical systems due to its long service life and weldability.
