A well-known producer and supplier of stainless steel 409 angles, Daksh Sheets and Plates serves customers in Delhi and all over India. We have a solid reputation for producing well-made, long-lasting stainless steel products, and we provide SS 409 angles that are perfect for industrial and structural uses. Our 409 stainless steel angles, which are produced in accordance with stringent quality control standards, offer an affordable option that is strong at high temperatures and resistant to corrosion. Daksh is a preferred partner for the infrastructure, automotive, fabrication, and construction industries because we guarantee timely delivery and consistent quality in a range of sizes and finishes.
Chromium (10.5–11.75%) and low carbon (≤0.08%) make up the majority of Stainless Steel 409, a ferritic stainless steel. Tiny amounts of titanium and other stabilising elements are added to enhance corrosion resistance and weldability. It has good formability and a moderate mechanical strength, with a tensile strength between 380 and 550 MPa. Additionally, at high temperatures, SS 409 provides outstanding resistance to exhaust gas oxidation and corrosion. It is ideal for structural and automotive applications requiring strength and moderate corrosion resistance because of its stable ferritic structure, which permits good dimensional stability and thermal conductivity.
| STANDARD | ASTM A240 |
| DIMENSIONS | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| THICKNESS | 3.0mm – 120mm |
| LENGTH | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| FINISH | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| TYPE | Angle |
| Grades | C | Ni | Si | S | Mn | P | Cr | Ti |
| SS 409 | 0.08 | 0.5 | 1.00 | 0.045 | 1.00 | 0.045 | 11.75 -10.5< | 0.75-6x C |
| Grades | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | Hardness (Brinell) MAX | Hardness (Rockwell B) MAX |
| SS 409 | 8.0 g/cm3 | 1457 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % | – | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Yes, we offer custom sizes for Stainless Steel 409 Sheet and Plates to meet specific project needs. Our team at Daksh Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@dakshsheetsandplates.co.in
| Grade | WERKSTOFF NR. | UNS | AFNOR | BS | JIS |
| SS 409 | 1.4512 | S40900 | Z3CT12 | 409 S 19 | SUS 409 |
Because of their exceptional heat and corrosion resistance, stainless steel 409 angles are used extensively in the industrial, automotive, and construction sectors. They are frequently employed in the production of catalytic converter parts, mufflers, and automobile exhaust systems. SS 409 angles are used as reinforcement, framing, and structural supports in heavy-duty fabrication, bridges, and buildings. They are also appropriate for railways, agricultural equipment, and HVAC systems due to their resilience in mildly corrosive environments. For applications requiring long service life and structural reliability, SS 409 angles are a sensible option due to their affordability, weldability, and performance under heat.
