Based in Delhi, India, Daksh Sheets and Plates is a reputable producer and supplier of stainless steel 410 sheets and plates. Daksh, which is renowned for producing high-quality stainless steel products, provides a large selection of industrial-grade sheets and plates to satisfy a variety of engineering and manufacturing requirements. Our SS 410 sheets and plates are ideal for a variety of applications because they prioritise precision, longevity, and resistance to corrosion. We guarantee that every product satisfies both domestic and international standards, providing excellent customer service and timely delivery to industries like machinery, automotive, and construction.
The martensitic grade of stainless steel 410 has a carbon content of about 0.15% and 11.5–13.5% chromium, which increases its hardness and strength. Small amounts of silicon, phosphorus, sulphur, and manganese are also present. With a tensile strength of 480–680 MPa, yield strength of 270 MPa, and elongation of 20%, SS 410 has exceptional mechanical qualities. It is very machinable and resists corrosion well in mild conditions. Its hardness can be further increased by heat treatment, which makes it perfect for uses requiring moderate corrosion resistance and wear resistance.
| Standard | ASTM A240, ASME SA240 |
| Dimensions | ASTM, ASME, and API |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Thickness | 4mm-100mm |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface Finish | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated) etc |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | Cr | Mn | Si | Ni | C | P | S | Fe |
| SS 410 | 11.50 – 13.50 | 0.0 – 1.50 | 0.0 – 1.00 | 0.0 – 0.75 | 0.08 – 0.15 | 0.0 – 0.04 | 0.0 – 0.02 | Balance |
| Tensile Strength Ksi (Mpa) | 0.2% Offset Yield Strength Ksi (Mpa) | Elongation, % in 2″ (51 mm) | Hardening Response HRC | HRB |
| 65 (450) – 74 (510) | 30 (205) – 42 (290) | 20 – 34 | 38-45 | 82-96 |
| Grade | WERKSTOFF NR. | UNS | AISI | BS | SIS | EN | JIS | AFNOR |
| SS 410 | 1.4006 | S41000 | 410 | 410S21 | 2302 | X12Cr13 | 410 | Z10C13/Z13C13 |
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/0C) | Thermal Conductivity (W/m.K) | Specific Heat 0-1000C (J/kg.K) | Electrical Resistivity (n.m) | |||
| 0-1000C | 0-3150C | 0-5380C | at 1000C | at 5000C | |||||
| 410 | 7750 | 200 | 9.9 | 11.4 | 11.6 | 24.9 | 28.7 | 460 | 570 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Because of its great strength, resistance to corrosion, and resistance to wear, stainless steel 410 sheets and plates are used extensively in many different industries. Cutlery, kitchenware, pumps, shafts, and valve parts are examples of common uses. They serve as structural supports and architectural panels in construction. They are used in the oil and gas industry in equipment and piping systems, and in the automotive industry for exhaust systems and trim parts. Because of their versatility, they can also be used for industrial equipment, surgical instruments, and machine parts, providing a dependable and affordable answer to a range of engineering and business requirements.
