Based in Delhi, India, Daksh Sheets and Plates is a top producer and supplier of stainless steel 415 sheets and plates. Our speciality is manufacturing premium-grade SS 415 sheets and plates that satisfy international quality standards, and we are dedicated to providing high-performance materials. Our highly skilled technical staff and state-of-the-art manufacturing facilities guarantee precisely engineered products perfect for structural and industrial applications. Our Stainless Steel 415 products, which come in a range of sizes, thicknesses, and finishes, are renowned for their strength, durability, and resistance to corrosion. Daksh guarantees prompt delivery and client satisfaction with each order, catering to both domestic and international markets.
The martensitic grade of stainless steel 415 is renowned for its moderate resistance to corrosion and high strength. Chromium (12–14%), carbon (0.15-0.20%), manganese (1.0%), silicon (1.0%), and trace elements like phosphorus and sulphur make up its usual chemical composition. It has outstanding mechanical qualities, including a yield strength of 450–600 MPa, a tensile strength of 700–850 MPa, and a hardness of 200–250 HB. Its strength and hardness are increased by heat treatment, which qualifies it for demanding industrial settings. It is appropriate for fabrication and heavy-duty tasks due to its moderate machinability and weldability.
| Specifications : | ASTM A240 / ASME SA240 |
| Dimensions : | ASTM, ASME and API |
| Standard : | JIS, AISI, ASTM, GB, DIN, EN, etc. |
| Surface : | 2B, 2D, BA, NO.4, NO.8, 8K, Mirror,Checkered, Embossed, Hair Line, Sand Blast, Brush, Etching |
| Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm,etc. |
| Finish : | Black,Bright Polished,Rough Turned,No.4 Finish,Matt Finish,BA Finish |
| Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc. |
| Grade | C | Mn | P | S | Si | Ch | Ni | Mo |
| SS 415 | 0.05 max | 0.50-1.00 | 0.030 max | 0.030 max | 0.60 max | 11.5-14.0 | 3.5-5.5 | 0.50-1.00 |
| Tensile Strength R₃ N/mm² | 700-800 | 700-800 | 700-800 | 700-800 | 700-800 | 700-800 | 700-800 |
| 0.2% Offset Yield Strength Rᵖ ≥N/mm² | 520 | 520 | 520 | 520 | 520 | 520 | 520 |
| Elongation in 2 inches, % | 15 min | 15 min | 15 min | 15 min | 15 min | 15 min | 15 min |
| Grade | WERKSTOFF NR. | UNS | AISI |
| SS 415 | 1.4313 | S41500 | F6NM |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | Density lbm/in3 | Melting Range(°F) | Thermal Conductivity(BTU-in/hr- ft. °F) | Electrical Resistivity(in x 10-6) | Modulus of Elasticity (psi x 106 | Coefficient of Thermal Expansion (in/in)/°F x 10-6 | Specific Heat(BTU/lb/°F) |
|---|---|---|---|---|---|---|---|
| 415 | -at 68°F: 0.280 | 2700 to 2790 | 187 at 212°F | 23.7 at 68°F | 29 | 6.0 at 32 – 212°F | 0.11 at 68°F to 212°F |
| – | – | – | – | – | 7.5 at 68 – 1200°F | – |
| Metric | density (g/cm³) | x | T | x | W | x | L | = | weight |
|---|---|---|---|---|---|---|---|---|---|
| Example | 4.50g/cm³ | x | 6mm | x | 2m | x | 1m | = | 54.00 kg |
| Imperial | density (lbs/in³) | x | T | x | W | x | L | = | weight |
| Example | 0.163 lbs/in³ | x | 4in | x | 48in | x | 144in | = | 4506.6 lbs |
Because of their exceptional mechanical strength and moderate resistance to corrosion, stainless steel 415 sheets and plates are used extensively in a variety of industries. Manufacturing of industrial blades, fasteners, pump shafts, valves, and machine parts are examples of common applications. These sheets and plates are also used for components that need to be strong and resistant to wear in the petrochemical, power generation, automotive, and construction industries. They are perfect for heavy-duty tools, pressure vessels, and structural frameworks because of their resilience to high stress. They are a crucial material for applications needing a balance of toughness, hardness, and fabrication flexibility because of their versatility.
