Based in Delhi, India, Daksh Sheets and Plates is a reputable manufacturer and supplier that specialises in high-end metal goods, such as Super Duplex Steel S32760 Circles. These circles are perfect for demanding industrial applications because of their remarkable strength, resistance to corrosion, and ability to function in harsh environments. Daksh produces S32760 circles that satisfy international standards by utilising sophisticated manufacturing techniques and strict quality standards. The company, which serves the offshore, marine, chemical, and power generation sectors, is dedicated to quality, on-time delivery, and client satisfaction. Daksh is a well-known brand in metal solutions with a significant presence in both domestic and foreign markets.
About 24–26% chromium, 6–8% nickel, 3–5% molybdenum, 0.2–0.3% nitrogen, and trace amounts of manganese, silicon, and iron make up Super Duplex Steel S32760 Circle. In harsh chloride environments, this well-balanced composition provides exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking. With a typical tensile strength of about 800 MPa, yield strength of about 550 MPa, and elongation of 25%, S32760 mechanically provides high strength. It is perfect for applications in extremely corrosive and high-pressure industrial environments because it also offers exceptional impact toughness and fatigue resistance.
| Specifications | ASTM A240 / ASME SA240 |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Thickness | 1 mm To 100 mm |
| Diameter | Upto 2000 mm |
| Circle | 3″ DIA up to 38″ DIA 1500 lbs max |
| Rings | 3″ OD up to 48″ OD Up to 900 lbs max |
| Cutting | Plazma & Machined Cut |
| Finish | HR, CR, 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Cold Rolled Circle, Small Flat Circle, Industrial Circle, Perforated Circle, Forged Steel Circles, Cnc Finish Circle, Polished Unique Circle, Hot Rolled Circle, Fey Laminar Rings, Proof Machined Rings, Cold Rolled Rings, Hot Rolled Rings, McInnes Rolled Rings, Die-Formed Rings, Forging Rings, CNC Machined Rings. |
| STANDARD | WERKSTOFF NR. | UNS |
| Super Duplex S32760 | 1.4410 | S32760 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32760 | 0.05 max | 1.00 max | 1.00 max | 0.030 max | 0.010 max | 24.00 – 26.00 | 3.00 – 4.00 | 6.00 – 8.00 | 0.20 – 0.30 | 57.61 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S32760 | 7.8 | 0.281 | 1350 | 2460 |
Daksh Sheets and Plates based in Hyderabad , India, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Yes, we offer custom sizes for Super Duplex Steel S32760 Circle to meet specific project needs. Our team at Daksh Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@dakshsheetsandplates.co.in
| Size | 18 G. | 19 G. | 20 G. | 22 G. | 24 G. | 26 G. |
| .4.5 | .0-107 | 0-085 | 0-080 | 0-062 | 0.049 | 0-040 |
| 5 | 0-120 | 0-095 | 0-090 | 0-070 | 0-055 | 0-045 |
| 5.5 | 0-146 | 0-119 | 0-109 | 0-085 | 0-066 | 0-054 |
| 6 | 0-172 | 0-136 | 0-130 | 0-100 | 0-079 | 0-064 |
| 6.5 | 0-200 | 0-153 | 0-150 | 0-128 | 0-093 | 0-074 |
| 7 | 0-235 | 0-190 | 0-176 | 0-136 | 0-107 | 0-088 |
| 7.5 | 0.270 | 0.212 | 0.201 | 0-157 | 0-123 | 0-100 |
| 8 | 0-307 | 0-240 | 0-230 | 0-180 | 0-140 | 0-115 |
| 8.5 | 0-347 | 0-270 | 0-262 | 0-202 | 0-156 | 0-130 |
| 9 | 0-388 | 0-330 | 0-301 | 0-230 | 0-178 | 0-145 |
| 9.5 | 0-472 | 0-342 | 0-324 | 0-252 | 0-198 | 0-162 |
| 10 | 0-480 | 0-380 | 0-360 | 0-280 | 0-220 | 0-180 |
| 11 | 0-580 | 0-450 | 0-435 | 0-338 | 0-266 | 0-218 |
| 12 | 0-690 | 0-540 | 0-518 | 0-403 | 0-318 | 0-253 |
| 13 | 0-811 | 0-640 | 0-508 | 0-608 | 0-371 | 0-304 |
| 14 | 0-940 | 0-750 | 0-708 | 0-558 | 0-430 | 0-352 |
| 15 | 1-080 | 0-860 | 0-808 | 0-650 | 0-495 | 0-405 |
| 16 | 1-228 | 0-960 | 0-921 | 0-736 | 0-563 | 0-460 |
| 17 | 1-382 | 1-080 | 0-940 | 0-809 | 0-635 | 0-560 |
| 18 | 1-595 | 1-200 | 1-116 | 0-907 | 0-712 | 0-683 |
| 19 | 1-732 | 1-350 | 1-300 | 1-010 | 0-794 | 0-750 |
| 20 | 1-920 | 1-400 | 1-340 | 1-120 | 0-880 | 0-785 |
| RAW MATERIAL | MAX. HARDNESS | TEMPERATURE | ABBREVIATIONSMARKER | |
| BRUCELLOSIS | ROCKWELL | |||
| SOFT IRON | 90 | 56 | -60 540 | D |
| LOW CB STEEL | 120 | 68 | -40 540 | S |
| 304SS | 160 | 83 | -250 700b | 304 |
| 304LSS | 150 | 83 | -250 450 | 304L |
| 316SS | 160 | 83 | -200 700b | 316 |
| 316LSS | 150 | 83 | -200 450 | 316L |
| 321SS | 160 | 83 | -200 700b | 321 |
| 347SS | 160 | 83 | -200 700b | 347 |
| 410SS | 170 | 86 | -40 650 | 410 |
| 5Cr-0.5Mo | 130 | -29 650 | ||
| COPPER | 80 | -100 315 | ||
| ALUMINUM | 35 | -200 425 | ||
| INCONEL 600 | 150 | -100 1095 | ||
| INCOLOY 825 | 160 | -100 1095 | ||
| MONEL 400 | 150 | -100 760 | ||
| TITANIUM | 215 | -200 540 | ||
| NICHEL 200 | 110 | -200 760 | ||
| HASTELLOY C276 | 200 | -100 1095 | ||
Industries that require high mechanical strength and exceptional corrosion resistance frequently use Super Duplex Steel S32760 Circles. Common uses include marine engineering, subsea pipelines, and offshore oil and gas platforms, where it is essential to have resistance to chloride-induced stress corrosion. They are utilised in storage tanks, pressure vessels, and heat exchangers in the chemical and petrochemical industries. Additionally, S32760 circles are perfect for structural elements in challenging conditions, pulp and paper processing, and desalination plants. They are a dependable option for crucial applications subjected to harsh media and high pressure because of their exceptional toughness, durability, and low maintenance needs.
