Based in Delhi, India, Daksh Sheets and Plates is a well-known producer and supplier of Super Duplex Steel Sheet and Plates S32750. Our speciality is providing steel plates with high strength and resistance to corrosion that satisfy the exacting requirements of contemporary industrial settings. Our S32750 sheets and plates are made with high-quality raw materials and sophisticated manufacturing techniques, and they are designed to endure high temperatures, pressures, and corrosive environments. Offering dependable solutions for structural and process-related applications, Daksh serves vital industries like the oil and gas, marine, desalination, power, and chemical sectors with consistent quality, on-time delivery, and adherence to international standards.
The dual-phase microstructure of Super Duplex Steel S32750 Sheets and Plates, which is composed of ferrite and austenite, provides exceptional strength and resistance to corrosion. Nitrogen, 6–8% nickel, 3–5% molybdenum, and 24–26% chromium are usually included in the composition. A PREN (Pitting Resistance Equivalent Number) higher than 40 is a result of these factors. The material has an elongation of 25%, a tensile strength of about 800 MPa, and a minimum yield strength of 550 MPa. It is perfect for harsh and chloride-rich service environments because of its exceptional resistance to stress corrosion cracking, erosion, and pitting.
| Standard Specification : | Super Duplex Fittings |
| Coating Fitting Faces : | Cold and Hot Dip Galvanized, Zinc Plated, Yellow Transparent, Oil Black Paint, Anti-rust Paint |
| Thickness: | View Our Thickness: Schedule 5S, SCH10, SCH20, SCH10, SCH20, SCH30, SCHTD, SCH40, SCH60, XS, SCH80, SCH100, SCH120, SCH140, SCH160. |
| Rating Pressure: | Pressure Rating Of: 3000 LBS, 6000 LBS, 9000 LBS |
| Check Sizes: | (SMLS UPTO 24”) 1/2” TO 36” (Buttweld 8” TO 36” ) |
| Standard: | MSS-SP-43 Type B Fittings, ANSI B16.28 Fittings, JIS B2312 Fittings, JIS B2313 Fittings, ANSI B16.9 Fittings, MSS-SP-43 Type A Fittings, MSS-SP-43 Type b Fittings |
| Dimensions Class: | 2000#, 3000#, 6000#, 9000# |
| Application: | Chemical Industry Water Pipeline Industry Nuclear Power Plant Natural Gas Industry Fabrication Industry Oil And Gas Industry |
| Fitting Machining Equipment: | Press machine, electric bevelling machine, Bending machine, Pushing Machine, Sand-blasting machine etc |
| Element | C | Mn | Si | P | S | Cr | Ni | Mo | N | Fe |
| Super Duplex Steel Pipe Fittings S32750 | 0.030 max. | 2.00 max. | 1.00 max. | 0.030 max. | 0.020 max. | 21.0 – 23.0 | 4.50 – 6.50 | 2.50 – 3.50 | 0.08 – 0.20 | 63.54 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Super Duplex Steel Pipe Fittings S32750 | 7.805 | 0.285 | 1420 – 1465 | 2588 – 2669 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Yes, we offer custom sizes for Super Duplex Steel Sheet and Plates S32750 to meet specific project needs. Our team at Daksh Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@dakshsheetsandplates.co.in
| Sheet & Plate Surface finish | Gauge (in) | Width (max in) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed Plate | 10–24 | 72* |
| 2D – Cold rolled, heat treated, pickled plate | 12–24 | 60 |
| BA Mexinox only | 18–28 | 48 |
| Polished Sheet (not brushed) | 11–24 | 60 |
| Temper rolled Sheet Mexinox only | 13–29 | 48 |
| Plate Thickness (mm) | Weight (kg/m) | kg/meter (width 1200mm) | kg/meter (width 1500mm) | kg/meter (width 1800mm) | kg/meter (width 2400mm) |
| 3 | 23.55 | 28.3 | 35.3 | 42.4 | 56.5 |
| 4 | 31.4 | 37.7 | 47.1 | 56.5 | 75.4 |
| 5 | 39.25 | 47.1 | 58.9 | 70.7 | 94.2 |
| 6 | 47.1 | 56.5 | 70.7 | 84.8 | 113 |
| 8 | 62.8 | 75.4 | 94.2 | 113 | 150.7 |
| 10 | 78.5 | 94 | 118 | 141 | 188 |
| 12 | 94.2 | 113 | 141 | 170 | 226 |
| 16 | 125.6 | 151 | 188 | 226 | 301 |
| 20 | 157 | 188 | 236 | 283 | 377 |
| 22 | 172.7 | 207 | 259 | 311 | 415 |
| 25 | 196.25 | 236 | 294 | 353 | 471 |
| 28 | 219.8 | 264 | 330 | 396 | 528 |
| 32 | 251.2 | 301 | 377 | 452 | 603 |
| 36 | 282.6 | 339 | 424 | 509 | 678 |
| 40 | 314 | 377 | 471 | 565 | 754 |
| 45 | 353.25 | 424 | 530 | 636 | 848 |
| 50 | 392.5 | 471 | 589 | 707 | 942 |
| 55 | 431.75 | 518 | 648 | 777 | 1036 |
| 60 | 471 | 565 | 707 | 848 | 1130 |
| 65 | 510 | 612 | 765 | 918 | 1224 |
| 70 | 549.5 | 659 | 824 | 989 | 1319 |
| 75 | 588.75 | 707 | 883 | 1060 | 1413 |
| 80 | 628 | 754 | 942 | 1130 | 1507 |
| 90 | 706.5 | 848 | 1060 | 1272 | 1696 |
| 100 | 785 | 942 | 1178 | 1413 | 1884 |
Industries that work in extremely corrosive and stressful environments frequently use Super Duplex Steel Sheets and Plates S32750. These consist of marine structures, chemical processing facilities, desalination systems, offshore oil platforms, and subsea pipelines. They are perfect for load-bearing and structural applications because of their high strength-to-weight ratio and superior resistance to corrosion caused by chloride stress. They are also utilised in heat exchangers, storage tanks, and pressure vessels where robustness and security are crucial. The S32750 grade is a preferred material in critical infrastructure and process equipment because it guarantees longer service life, less maintenance, and cost effectiveness.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
