Serving customers from Delhi, India, and beyond, Daksh Sheets and Plates is a top producer and supplier of high-quality metal products. We are experts in producing Titanium Grade 5 Foil and other high-performance materials, with a particular emphasis on accuracy, robustness, and client satisfaction. We serve the aerospace, medical, marine, and defence industries and are renowned for our state-of-the-art manufacturing techniques and strict quality controls. Our Titanium Grade 5 Foil is a reliable partner for cutting-edge engineering applications because of its remarkable strength-to-weight ratio, resistance to corrosion, and thermal stability.
Standards : ASTM B265 / ASME SB265
Width : 3.2mm – 1500mm
Form : Coils, Foils, Rolls, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Thickness : 0.1mm to 12 mm Thk
Length : 500mm to 12000mm
Width : 100mm to 3000mm
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 5 | 3.7164 / 3.7165 | R56400 |
| Grade | C | Ti | O | Fe | Ai | V |
| Titanium Gr. 5 | 0.25 max | 90 min | 0.2 max | 0.25 max | 6 min | 4 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
About 90% titanium, 6% aluminium, and 4% vanadium make up Titanium Grade 5 Foil, also referred to as Ti-6Al-4V. This alpha-beta alloy has exceptional mechanical performance, a high strength-to-weight ratio, and exceptional corrosion resistance. With an elongation of 10% and a yield strength of about 828 MPa, its typical tensile strength is about 895 MPa. Even at high temperatures, the alloy retains good fatigue strength and thermal stability. It is perfect for demanding environments that demand both precision and durability because of its sturdy structure and lightweight design.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Daksh Sheets and Plates based in Hyderabad , India, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Titanium Grade 5 Foils offer numerous advantages, including exceptional strength-to-weight ratio, making them ideal for lightweight yet durable applications. They exhibit outstanding corrosion resistance, even in harsh environments like seawater and chemicals, ensuring longevity and reliability. Additionally, Grade 5 titanium is highly biocompatible, making it perfect for medical implants and devices. The alloy also maintains high strength at elevated temperatures, offering excellent performance in aerospace and automotive sectors. Its fatigue resistance, low thermal expansion, and resistance to wear and stress make it a versatile and high-performing material for diverse industries.
| Size (mm) | Weight per (Kg) | Size (mm) | Weight per (Kg) |
|---|---|---|---|
| 2000 x 1000 x 2.0 | 32.7 | 2000 x1000 x 0.9 | 14.7 |
| 3000 x 1500 x 1.5 | 55.3 | 2500 x1250 x 0.7 | 17.9 |
| 3000 x 1500 x 2.0 | 73.7 | 2000 x1000 x 1.0 | 16.4 |
| 2500 x 1250 x 1.5 | 38.4 | 2000 x1000 x 0.7 | 11.5 |
| 3000 x 1500 x 3.0 | 112.0 | 2000 x1000 x 1.5 | 24.6 |
| 2500 x 1250 x 2.0 | 51.2 | 2500 x1250 x 0.9 | 23.0 |
| 2000 x 1000 x 2.5 | 40.9 | 2500 x1250 x 1.0 | 25.6 |
| 2500 x 1250 x 2.5 | 63.9 | 3000 x1500 x 1.0 | 36.8 |
| 2500 x 1250 x 3.0 | 77.5 | 3000 x1500 x 1.2 | 44.2 |
| 3000 x 1500 x 2.5 | 92.1 | 2000 x1000 x 1.2 | 19.6 |
| 2000 x 1000 x 3.0 | 49.6 | 2500 x1250 x 1.2 | 30.7 |
Yes, we offer custom sizes for Titanium Grade 5 Foils to meet specific project needs. Our team at Daksh Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@dakshsheetsandplates.co.in
Titanium Grade 5 Foil is widely used across a variety of high-performance industries due to its superior mechanical properties and corrosion resistance. In aerospace, it is utilized in turbine engines, airframes, and structural components. The medical field employs it for surgical instruments, implants, and dental applications due to its biocompatibility. In marine environments, it resists saltwater corrosion, making it suitable for ship components and offshore equipment. Additionally, it finds use in the automotive, chemical processing, and energy sectors. Its thin, flexible form allows for easy fabrication in precision engineering, electronics shielding, and high-temperature industrial applications.
